Bird-X Peller PRO Manual

HIGH will increase sound output.
CAUTION: Take care when turning the dial since the unit may be in
an inactive state when the dial is rotated. It could then reactivate at
a very high level of sound which could be painful to your ears.
POWER SWITCH (INT/EXT. SPKR)
The power switch enables the unit to operate.
Slide the switch to the INT/EXT. SPKR (ON)
position to start the unit. This will operate the unit,
and generate sound out of the unit AND out of an
optional extension speaker at the same time. If
you wish to operate ONLY a remote extension
speaker (optional), then move the switch to the
EXT. SPKR ONLY position.
If you turn the unit OFF, be sure to leave it off
for about 30 seconds before turning it back on to
allow the electronics to properly reset. To fully
disconnect the unit, unplug the power adapter from
the electrical outlet or disconnect the battery cable
from the 12-volt battery.
TROUBLESHOOTING
PROBLEM | SOLUTION
• Check volume settings
Unit is on,
• Check time of operation settings.
but no sound is heard
• Check that at least one bird is
selected to play.
Unit is on, but plays the
• Reset the unit by turning it off for
same bird over and over,
30 seconds and then back on.
regardless of settings
• Double check Mode switch
settings
Unit is not operating
• Make sure photocell is not
properly in the obstructed.
DAY or NIGHT mode
• Make sure the photocell is not
affected by bright lights in either
the front or the back of the unit.
• Check battery condition
Unit does not function
• Turn power switch on the unit to
properly when connected
the OFF position. Reconnect the
battery, wait 30 seconds, then
to a 12 volt battery
switch the unit back on
Limited Warranty
This BirdXPeller Pro Unit is warranted against
defects in material and workmanship for six months
from date of purchase (extended warranty available).
Bird-X will replace or repair, provided defect occurs
under normal use. Returns accepted only authoriza-
tion from our Chicago office.
Successful Long-Term Behavior Modification
Product success takes time to build. Bird and pest habits
may take several days or weeks to break. Follow all
suggestions for maximum efficacy. "Instant" tests do not
replicate natural conditions and give no indication of the
unit's success with the infestation.
Prepare for Successful Bird Control
Bird-X, Inc. has been recognized worldwide as the bird
control x-perts for 40 years. We have become experts
through extensive experience and research.
result, we are happy to analyze problems and make
reommendations based on each customer's specific
situation and needs. In addition, we provide the following
recommendations for greatest success, even before
activating the repeller.
Remove inducements. Clean the area of all evidence
of birds: nests, fledglings, droppings, dead birds, and
the residential scent. Because birds and their droppings
can carry many diseases, use extreme caution when
removing them. Do not breathe or come into direct
contact with them. If you have questions about how to
do this safely, consult an expert. (Adult birds are likely
to return to their young in order to protect them or to
assist them in leaving the area.) Remove food spillage,
garbage, nesting material and other appealing items.
Survey the birds to determine flight and time patterns,
entries and exits, and nesting, feeding and roosting
habits. This will suggest the unit placement, speaker
direction and time of operation you should choose. Make
educated guesses as to where the birds will go when they
are repelled from their current infestation, and consider
additional units to cover these alternative areas.
Maintain a clean and changing environment. Periodically
clean the area of nests and droppings, relocate or
reposition the unit, vary the output, or turn off the unit for
a short time.
Install early, before "bird season" begins, as it is easier to
keep the birds away than to rout them out once they have
established a living pattern.
Use products synergistically. Two or more different
kinds of devices (this repeller plus a visual scare product
and/or a roost inhibiting device) will produce a synergistic
effect -- i.e., in combination, the products will yield much
greater effectiveness than the one alone. Contact us for
information on "companion" products.
300 North Elizabeth Street • Chicago, IL 60607
ph. (312) 226-2473 • fax (312) 226-2480
Toll Free US & Canada 800-662-5021
www.bird-x.com • sales@bird-x.com
EPA Est. No. 075130-OR-001
BirdXPeller Pro 2 Instructions P/N 655-0050-00 (BXP#2) rev. G
Digital Bird Repeller
INSTALLATION
As a
Important safety-related information:
a) Do not install the device during rain or snow
conditions.
b) Installation shall be made in such a way that a
power supply and the internal part of the control unit
never be subjected to water or snow.
c) Note that the power supply is intended for dry
location use only.
1) Point the unit toward the
bird infestation. Expect a
maximum coverage area
of approximately 1 acre in a
long dispersion pattern. Set
the unit on a flat surface or
mount it to a wooden post
using the mounting bracket
and screws (included).
2) Plug one end of the AC adapter into the POWER
jack (located on the back of the unit). Plug the
adapter into any standard electrical outlet.
optional battery cable may be used to connect the
control unit to a 12-volt battery. If this is done, first
connect the black battery clip to the negative terminal
on the battery and then connect the red battery clip
to the positive terminal. Both the connection to the
electrical outlet (or battery) and the connection of the
power cable inside the control unit must be protected
from dripping or splashing water. Do not set an
object filled with liquids on the control unit.
3) Set the DIP switches located on the front metal
faceplate of the unit, (see Switch Array #1 and
Switch Array #2) to the desired settings. See the
section "Programming your BirdXPeller PRO" for
specific programming information.
4) Turn the volume switch to LOW (Minimum).
