Bird-X MEGABLASTER Quick Start Manual

selected recordings in a sequential order. The
Random Mode is recommended to keep birds from
adapting to a preset pattern of sounds. To operate
the unit in Random mode, set switch 5 in Mode
settings as follows:
Switch 5 Mode
ON Random mode ON
OFF Random mode OFF
PROGRAMMING EXAMPLE
Recording Switches: Results
1, 3, 5 and 6 to "ON" position Plays Bird 1, 3, 5 & 6
Mode Switches
1 = "OFF" position
2 = "ON" position (Medium), every 1 to 4 minutes
3 = "ON" position
4 = "OFF" position Operates during daylight hours only
5 = "ON" position In random, non-sequential order
VOLUME CONTROL
The unit has a volume control dial on the front panel
of the unit. Turning the dial toward low will result in
reduced sound output and rotating the dial toward
high will result in an increase in sound output.
CAUTION: Take care when turning the dial since the unit may
be in an inactive state when the dial is rotated. It could then
reactivate at a very high level of sound which could be painful
to your ears.
POWER SWITCH
The power switch enables the unit to operate.
Slide the switch to the ON position to start the
unit. If you turn the unit OFF, be sure to leave it off
for about 30 seconds before turning it back on to
allow the electronics to properly reset.
TROUBLESHOOTING
PROBLEM SOLUTION
• Check volume settings.
Unit is on,
• Check time of operation settings.
but no sound is heard
• Check that at least one bird is
selected to play.
Unit is on, but plays the
same bird over and over, Reset the unit by turning it off
for 30 seconds and then back on.
regardless of settings
• Double check Mode
switch settings.
Unit is not operating • Make sure photocell
is not obstructed.
properly in the
DAY or NIGHT mode • Make sure the photocell is
not affected by bright lights
in either the front or the
back of the unit.
• Check battery condition.
Unit does not function
• Turn power switch on unit
properly when connected
to the OFF position.
to a 12 volt battery Reconnect the battery,
wait 30 seconds, then
switch the unit back on.
LIMITED WARRANTY
IF YOU ARE NOT COMPLETELY SATISFIED, CONTACT THE PLACE
OF PURCHASE OR OUR CUSTOMER SERVICE DEPARTMENT
WITHIN 1 YEAR OF YOUR DATE OF PURCHASE FOR PROMPT AND
COURTEOUS REPLACEMENT, REPAIR OR REFUND.
BIRD-X INC'S LIABILITY HEREUNDER SHALL BE LIMITED TO
REFUNDING THE PURCHASE PRICE PAID BY CUSTOMER OR
REPLACING THE PRODUCT, IN BIRD-X'S SOLE DISCRETION,
AND UNDER NO CIRCUMSTANCES SHALL BIRD-X INC BE LIABLE
FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES, OF ANY
NATURE WHATSOEVER, ARISING FROM THE CUSTOMER'S USE OR
OPERATION OF THE PRODUCT; PROVIDED, HOWEVER, THAT THIS
LIMITATION MAY BE LIMITED BY STATE LAW.
EXCEPT FOR THE EXPRESS ONE-YEAR LIMITED WARRANTY
SPECIFICALLY DESCRIBED HEREIN, BIRD-X INC DISCLAIMS ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED, RELATING TO THE
PRODUCT, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR IMPLIED WARRANTY OF
FITNESS; AND THE EXPRESS WARRANTIES ARE IN LIEU OF ALL
OBLIGATIONS OR LIABILITIES ON THE PART OF BIRD-X INC
ARISING OUT OF OR IN CONNECTION WITH THE SALE, USE, OR
OPERATION OF THE PRODUCT.
BIRD-X, INC
300 N. ELIZABETH ST
CHICAGO, IL 60607
1-800-662-5021 • Fax 312 226-2480
sales@bird-x.com • www.bird-x.com
EPA Establishment Number 62617-OR-001
Bird-X MEGABLASTER
Digital Bird Repeller
BIRD-X MEGABLASTER
PRIOR TO INSTALLATION
Your complete Bird-X
Mega-Blaster kit includes
a control unit, 40 watt solar
panel, battery cable with
clips and a 20 speaker
tower. Open the control unit
by lifting the two latches on
the side of the enclosure.
Prior to operation, route the
speaker and power cables
from their respective jacks
on the control panel down
through the cable strain
Cable Strain Relief
relief in the lower part of the
enclosure.
IMPORTANT: Be certain that
the power switch is in the OFF
position and the volume control is
set to the minimum (LOW) volume
level (counterclockwise) as
shown in Fig. 1 when powering up
the unit.
SETUP AND INSTALLATION
1) Use the mounting hard-
ware (included) to mount
the control unit box to a
wall, post, pole or other
vertical surface.
2) Attach the battery cable
assembly to a 12V battery
(not included) matching
the positive and negative
terminals. The other end
of the cable comes prein- Complete system shown
mounted on a pipe
stalled into the power ter-
minal block. Attach the
Fig. 1
with solar panel.
