INSTALLATION

Installation of the exhaust pipe
This unit is a PORTABLE AIR CONDITIONER. It can be moved from room to room, so the cooling can
follow you anywhere. The mounting is easy, beneath a window or wall. Please refer to either of the
following steps:
Using the foam strips
1.
•
Connect the supplied foam strips with the exhaust pipe to let hot air flow to the outside. If
necessary cut off the extra part to fit the window.
•
Feed exhaust hose through the foam strip and insert strip into window gaps as shown and
slide window across so that foam is held securely. This technique may also be used for sash
windows. Note: Take care to maintain protection against intruders.
2. Using the adaptor
•
Cut a 130mm diameter hole in the wall or window.
•
Feed exhaust hose through the window or wall and attach the threaded adaptor from the
outside as shown.
•
When not in use, plug the hole with the cover provided.
