- Page 1 INSTRUCTION MANUAL 28-Inch Wicker Fire Pit Table SKY5672 + SKY5673 Ver. 3...
-
Page 2: If You Smell Gas
IF YOU SMELL GAS • Do not attempt to light appliance. • Extinguish flames and disconnect tank. • Move people away from the immediate area. bestchoiceproducts.com... -
Page 3: California Proposition
NOTICE Please retain these instructions for future reference. • For outdoor use only; do not use in a building, garage, or any other enclosed area. • Fire pit operates at reduced e ciency in temperatures below 40°F or wind velocity higher than 10 mph. •... -
Page 4: Tools Required
PROPANE TANK WARNINGS • Make sure to organize fuel hose to prevent accidental tripping. • Only use standard 20-pound propane tanks. • Maximum gas supply pressure is 250 PSI. • Do not fill tank more than 80% of its capacity. •... - Page 5 PARTS TABLETOP WITH LEFT PANEL BURNER 1 PC 1 PC 1 PC BACK PANEL RIGHT PANEL TANK SEAT FRAME 1 PC 1 PC 1 PC DOOR GLASS BEADS COVER 1 PC 1 SET 1 PC...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Attach part D back panel to part C left panel with two part 3 screws and two part 1 washers. Attach part F tank seat frame with two part 3 screws and two part 1 washers. - Page 7 PRODUCT ASSEMBLY Attach part E right panel with four part 3 screws and four part 1 washers.
- Page 8 PRODUCT ASSEMBLY Insert the part G door into the designated holes and secure with the magnetic catches.
- Page 9 PRODUCT ASSEMBLY Carefully flip the table base over and attach it to the part B tabletop with six part 2 screws and six part 1 washers. Place the part H glass beads (see Placing Glass Beads section).
-
Page 10: Back View
PRODUCT ASSEMBLY Place the part A lid. Hang lid on hangers when not in use. BACK VIEW... - Page 11 DIAGRAM GUARD BURNER HANGERS REGULATOR FUEL HOSE CONTROL PANEL COUPLING NUT PLACING GLASS BEADS • Place glass beads in fire pit and spread them according to your preference. - You may place glass beads around the burner but do NOT cover the guard. •...
- Page 12 INSTALLING PROPANE TANK NOTE: Only use standard 20-pound propane tanks. Pull handle and remove door. Place propane tank on the tank seat frame. Turn wingnut clockwise to secure tank. Make sure release valve on tank is firmly screwed shut. Attach fuel hose regulator to the output Turn release valve on tank counterclockwise of the tank by turning the coupling to release gas.
-
Page 13: Control Panel
CONTROL PANEL IGNITE CONTROL KNOB IGNITER: Push to light burner HIGH OPERATING INSTRUCTIONS NOTE: Before use, inspect burner, propane tank, and connectors for damage, debris, obstructions, or dirt. Do not operate if there is any blockage. Push and turn control knob counterclockwise to low/ignite. Press the ignitor button repeatedly to light burner. - Page 14 CLEANING • Make sure fire pit is completely cool before cleaning or storage. • Use a soft brush or cloth to wipe stains and dirt. • If necessary, clean with mild detergent and a soft cloth/sponge. • Black soot may develop on glass beads after use; use a damp cloth to clean debris as needed. •...
-
Page 15: Troubleshooting
TROUBLESHOOTING PROBLEM REASON SOLUTION Guard obstructed Clear guard of obstructions Burner not lighting Burner wet Dry burner with igniter Igniter battery dead Replace battery in igniter Replace/refill tank Propane tank is empty Coupling nut loose Fully tighten coupling nut Bent hose Straighten hose Burner does not light Remove obstructions or... -
Page 16: Help Center
HELP CENTER HELP CENTER Question about your product? We're here to help. Visit us at: Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com help.bestchoiceproducts.com CHAT CHAT Product Assembly Product Assembly Returns & Refunds Returns & Refunds PRODUCT WARRANTY INFORMATION PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long...
