BCP SKY4803 Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
READ BEFORE USE!
WARNING
USE PROPANE GAS ONLY!
-Do not store or use gasoline or other
flammable vapors in the vicinity of this or any other
appliance.
- Service must be performed by a qualified installer, service
agency or the gas supplier.
WARNING
For use with cylinders marked PROPANE only. DO NOT
connect to a remote gas supply.
If the fire pit is stored indoors, detach and leave propane
cylinder outdoors.
Design complies with ANSI Z21.97-2014 • CSA
2.41-(2014) Outdoor Decorative Gas Fireplaces .
OWNER'S MANUAL
1
Item No.:SKY4803 Fire Pit
WARNING
For Outdoor Use Only! Use Propane Gas Only !
Propane cylinders sold separately.
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause injury or property
damage. Read the owner's manual thoroughly
before installing or servicing this equipment. If the
information in this manual is not followed exactly, a
fire or explosion may result causing property
damage, personal injury or loss of life.
WARNING
The propane cylinder must be disconnected
when this fire pit is not in use.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and
i
mmediately call your gas supplier or fire department.
WARNING
This must be attended at all times!
WARNING
A propane gas tank not connected for use shall not be
stored in the vicinity of this or any other appliance.

Advertisement

loading

Related Manuals for BCP SKY4803

Summary of Contents for BCP SKY4803

  • Page 1 OWNER'S MANUAL Item No.:SKY4803 Fire Pit READ BEFORE USE! WARNING For Outdoor Use Only! Use Propane Gas Only ! Propane cylinders sold separately. WARNING Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the owner's manual thoroughly before installing or servicing this equipment.
  • Page 2 If you smell gas and/or hear a gas hissing sound: 1. Immediately, SHUT OFF gas to the appliance. 2. Extinguish ALL open flames. 3. If odor continues, keep away from the appliance and immediately call your Gas Supplier or Fire Department. Save this Owner's Manual and these instructions for future use.
  • Page 3 please read this entire Owner's Manual carefully. ould ould If the Propane Gas Tank is leaking gas, you can smell, hear a hiss, or sense a leak at the source. Do the following: 1.Disconnect the Propane Gas tank. 2.DO NOT attempt to fix the problem yourself. 3.Move yourself and all persons away from the immediate area.
  • Page 4 Pit. within 7 inches around the entire unit. that may catch fire such as dry vegetation,wood,branches,leaves,plants,buildings,structures,fabrics,clothing,sawdust,all chemicals,...
  • Page 5 ould...
  • Page 6 Pit.
  • Page 7 Part C. Pit . The picture on the next page shows different parts of the Charge Valve of the Gas Tank and the Regulator. kinds of Fire Pit. Fire Pit that has the Gas Tank i held Fire Pit Type 2: Fire Pit that has the Gas Tank externally visible. The hose should be NO SHORTER than 5 feet.
  • Page 8 Tank Tank Screw clockwise by brushing a mixture of soap Turn the gas supply on. If any large bubbles form on any connection there may be a leak. If you smell gas or a leak is discovered, IMMEDIATELY turn the gas valve off, disconnect Propane Gas tank.
  • Page 9 y required. Here is an introduction to all the parts that form your Fire Pit. Each part is different and holds its own function DO NOT attempt to change and or remove any parts. In the event of servicing and or operational issues,contact a qualified service technician. (Lava rock stored under the table)
  • Page 10 Valve with Gas Hose with Tank Holder...
  • Page 11 construct your...
  • Page 12 assembly. 2.Place 20lb. Propane Gas Tank (not included) into the tank holder(18). Make sure the Propane Gas Tank is placed completely into the tank holder(18). Turn the preassembled Wing Screw (17) in a clockwise direction into the Nut (17) to secure the Propane Gas Tank tightly.
  • Page 13 gas supply. 4.Unscrew and r slot(14). Make sure the positive side of the Battery(B) faces outwards. Screw the Electronic Igniter Cap(14) over the battery, tightly.
  • Page 14 Spread lava rocks over the burner rings. DO NOT block the guard(01). BLOCKED. Propane Tank...
  • Page 15 Fire Pit using the Fire Pit Fire Pit after the Fire Pit is lit.
  • Page 16 Fire Pit these counterclockwise. position.
  • Page 17 with lava rocks are completely cooled down. ,rust, components Valve(22).
  • Page 18 Fire Pit moisture absorption. ,it still requires proper care and maintenance. keep it from spreading absoption surface,compared to if they are left for extended periods on these surfaces. or eat on the surface of the fire pit. otherwise...
  • Page 19 in which...

  • Page 20: Helpful Tips

    Helpful Tips If the burner will not light or stay lit, please perform the following checks. It is possible that the Excess Flow Safety Device has been tripped. Turn the control knob to off and close the Gas tank valve. Disconnect Propane the regulator.

  • Page 21: Troubleshooting

    Troubleshooting Problem: Burner will not light using igniter Please review the Helpful Tips for common fixes to this problem. Possible Cause 1: Electrode and burners are wet. -Wipe dry with cloth. Possible Cause 2: Igniter battery is dead or backwards. -Check that the AAA battery is inserted correctly in the igniter (see page 10) or replace the battery.
  • Page 22 Troubleshooting Problem: Sudden drop in gas flow, or a reduced flame height Possible Cause 1: Out of Gas. -Check for gas in the Propane gas tank. Possible Cause 2: Excess flow safety device may have been activated. -Turn control knob to “OFF”, wait 30 seconds and light outdoor fire table. If flames are still too low, reset the excessive flow safety device by turning off...
