Summary of Contents for BCP SKY3289
- Page 1 INSTRUCTION MANUAL 57-Inch Rectangular Gas Fire Pit Table SKY3289 Ver. 2...
-
Page 2: If You Smell Gas
WARNING Do not use this product directly on a wood deck or near a side wall. IF YOU SMELL GAS • Do not attempt to light appliance. • Extinguish flames and disconnect tank. • Move people away from the immediate area. bestchoiceproducts.com... -
Page 3: California Proposition
NOTICE Please retain these instructions for future reference. • For outdoor use only; do not use in a building, garage, or any other enclosed area. • Fire pit operates at reduced e ciency in temperatures below 40°F. • Only use this appliance on a hard and level surface such as concrete or rock. •... -
Page 4: Tools Required
PROPANE TANK WARNINGS • Make sure to organize fuel hose to prevent accidental tripping. • Only use standard 20-pound propane tanks. • Maximum gas supply pressure is 250 PSI. • Do not fill tank more than 80% of its capacity. •... -
Page 5: Product Assembly
PARTS TANK SEAT FRAME DOOR PANEL FIRE GLASS 1 PC 1 PC 1 SET 1 PC COVER 1 PC PRODUCT ASSEMBLY Attach part F door panel to part C right panel and part D left panel with four part 1 screws and four part 3 washers. Attach part B back panel to left/right panels with four part 1 screws and four part 3 washers. - Page 6 PRODUCT ASSEMBLY Route the part 5 tank strap through the part E tank seat frame. Attach the tank seat frame to the panels with four part 1 screws and four part 3 washers. NOTE: Align numbers on the tank seat frame with the corresponding numbers on the panels. Attach the part A tabletop to the panels with four part 2 screws and four part 4 washers.
- Page 7 DIAGRAM GUARD BURNER CONTROL PANEL FUEL HOSE REGULATOR COUPLING NUT PLACING FIRE GLASS • Place fire glass in fire pit and spread them according to your preference. - You may place fire glass on burner but do NOT cover the guard. •...
- Page 8 INSTALLING PROPANE TANK NOTE: Only use standard 20-pound propane tanks. Open door and place propane tank on the tank seat frame. Clip tank straps to secure the propane tank. Make sure release valve on tank is firmly screwed shut. Attach fuel hose regulator to the output Turn release valve on tank counterclockwise of the tank by turning the coupling to release gas.
-
Page 9: Installing Battery
INSTALLING BATTERY Unscrew igniter button. Insert AAA battery with the positive side facing outwards. Replace igniter button. NOTE: If the burner is not lighting, you may need to replace the battery in the igniter. CONTROL PANEL CONTROL KNOB IGNITER: Push to light burner IGNITE... - Page 10 OPERATING INSTRUCTIONS NOTE: Before use, inspect burner, propane tank, and connectors for damage, debris, obstructions, or dirt. Do not operate if there is any blockage. Before first use (or after changing propane tanks), push and hold control knob for 2 minutes to expel air from fuel hose.
-
Page 11: Troubleshooting
TROUBLESHOOTING PROBLEM REASON SOLUTION Guard obstructed Clear guard of obstructions Burner not lighting Burner wet Dry burner with igniter Igniter battery dead Replace battery in igniter Replace/refill tank Propane tank is empty Coupling nut loose Fully tighten coupling nut Burner does not light Bent hose Straighten hose Remove obstructions or... -
Page 12: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
