3

Install the Print Head

Handle the Print Head carefully. Do not drop or
apply excessive pressure to it.
1
A
B
Press the
button (A).
The Front Tray (B) opens.
The Print Head Holder makes a noise as it moves. This is normal operation.
If the Print Head Holder does not move, make sure that the printer is turned on.
1
2
C
Open the Top Cover (C).
The Print Head Holder (D) comes out. (This is where you install the
Print Head.)
3
2
4
5
6
D
