BCN3D Sigma Series Quick Start Manual

User Guide in your own
language
For more detailed information about
the processes shown in this guide,
read the User Guide.
Unboxing video

Unboxing

Watch our video to see
how to correctly unbox.
Set up video
Install printing surface
Watch our video to see
how to correctly position
the printing surface.

Quick Start Guide

BCN3D Sigma Series
We would like to thank all users for trusting BCN3D, for helping us to reach our
dreams and to create a better product every day.
1. Unboxing
The printer is heavy and therefore this step needs to be performed by two people. Make sure
that the table where the printer is being installed, is close enough.
Retain packaging for warranty service.
1. Open the box from the
top.
2. Remove the components
from the foam and place
them on a table. Then
remove the foam and the
cardboard.

2. Set up

Remove protections

• Remove all the protection foams inside the printer. There are three on the carriage and one
under the printing surface.
Install plastic covers
• Take the plastic covers and thumbscrews from the packaging.
• Peel off the protective films.
• Use the thumbscrews to install the plastic covers.
Install printing surface
• Pivot the left and right spring clips away from the aluminium platform.
• Take the glass printing surface from the upper protective foam.
• Place the glass printing surface on top of the aluminium platform.
• Insert the glass with light force into the back spring clips.
• Fix it with the left and right spring clips.
The glass printing surface must be handled with care. In case of breakage, it may cause injuries.
3. Remove the lateral foam
protections.
Specifications subject to change. EN-MSS-2020-v1
Proper area to take out the
printer with your hands.
4. Lift the printer with care
holding it from the side
flanges and place it on the
table.
5. Open the plastic bag
containing the printer.
