Start Here
Easy Setup Instructions
Unpack the Machine
• Please confirm the included items against the illustration printed on the lid of the packing box.
• A USB cable is necessary to connect the machine with your computer.
QT5-0453-V02
1
Prepare the Machine
a
Place the machine on a flat and horizontal
surface, and do not place any objects in front
of the machine. Open the Front Feeder, and
extend the Paper Output Support and the Paper
Support.
Caution
Before turning on the machine, remove all of the shipping
tapes.
Important
Do not connect the USB cable until after the software is in-
stalled.
b
Plug the power cord in the back of the machine
and connect the other end to the wall outlet.
Important
• Plug the power cord all the way in, since it may be difficult to
plug.
• Make sure that the Document Cover is closed.
Open the Operation Panel, then press the ON/
c
OFF button to turn on the machine.
Use the { or } button on the Operation Panel to
d
select the language for the LCD, then press the
OK button.
(1) Press the { or }
button to select the
language.
(2) Press the OK
button.
Important
If an unintended language is displayed on the LCD, proceed
setup to the end of step 3 "Install the Ink Tanks", and then
refer to "An Unintended Language Is Displayed on the LCD"
in "Troubleshooting" of the User's Guide on-screen manual to
change the LCD language.
If the message <Install the print head and set the ink tank.>
appears, go to e.
e
Lift the Scanning Unit (Printer Cover) open, and
set the Scanning Unit Support to hold the cover.
The Print Head Holder moves to the center.
Scanning Unit (Printer Cover)
Write down the serial number located inside
f
the machine. You will need this to register your
product.
Serial Number Location
2
Install the Print Head
a
Remove the Print Head from its package.
Caution
There may be some transparent or light blue ink on the inside
of the bag the print head comes in, or the inside of the protec-
tive cap - this has no effect on print quality. Be careful not to
get ink on yourself when handling these items.
Remove the orange protective cap from the Print
b
Head and discard it.
Electrical Contacts
Protective Cap
Print Head Nozzles
3
Install the Ink Tanks
