BENDIX AutoVue FLC-20 Service Data page 9

Descriptions and Service Action Codes
DTC
78 J1939: Vehicle controller message missing - VDHR
79 J1939: Vehicle controller message missing - LCMD
80 J1939: Vehicle controller signal error - OEL Hazard Switch
81-86,
Internal Error
128-129
130 J1939: Vehicle controller message missing - TCO1
131 J1939: Brake controller message missing - EBC2
132 J1939: Brake controller message missing - EBC1
133 Brake Controller Mismatch - Incorrect Camera Lens Angle
134 J1939: Vehicle controller message missing - FLIC
139 J1939: Brake controller message missing - Prop FLC Status
140 Incompatible software version - Image Processor
141-145 Internal Error
146 Camera lens blocked
147 Camera temperature too high
148 J1939: Vehicle controller signal error - LDW Enable Switch
149 J1939: Engine controller signal error - CCVS1 Parking Brake
150 J1939: Brake controller signal error - EBC1 Brake Switch
151 J1939: Brake controller signal error - EBC2 Vehicle Speed
152 J1939: Engine controller signal error - EEC1 Engine Speed
153 J1939: Vehicle controller signal error - FLIC LDW Enable Command
154 J1939: LDW Speaker controller signal error - FLIC Prop Speaker
155 J1939: Vehicle controller signal error - LCMD Low Beam Headlamp
156 J1939: Vehicle controller signal error - LCMD High Beam Headlamp
157 J1939: Vehicle controller signal error - LD Low Beam Headlamp
158 J1939: Vehicle controller signal error - LD High Beam Headlamp
159 J1939: Vehicle controller signal error - OEL Turn Signal Switch
160 J1939: Vehicle controller signal error - OEL High-Low Beam Switch
161 J1939: Vehicle controller signal error - OEL High Beam Status
162 J1939: Vehicle controller signal error - OEL Wiper
163 J1939: Vehicle controller signal error - TCO1 Vehicle Speed
164 J1939: Vehicle controller signal error - VP37 Left Turn Signal
165 J1939: Vehicle controller signal error - VP37 Right Turn Signal
166 J1939: Vehicle controller signal error - VP37 High Headlamp
167 J1939: Vehicle controller signal error - VP37 Hazard Lamp
168 J1939: Vehicle controller signal error - VP37 Wiper Status
172 J1939: Engine controller signal invalid - EEC1 Engine Speed
173 J1939: Vehicle controller signal invalid - FLIC LDW Enable Command
174 J1939: Speaker controller signal invalid - FLIC Prop Speaker
176 J1939: Brake controller signal invalid - VDC2 Steering Angle Sensor
Note: The system will not report newly active J1939 DTCs until the engine has been
running for 15 seconds. Do not attempt to diagnose J1939 DTCs without the engine running.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
Table 1 – DTC Code to Service Action Code (Pages 8–10)
Diagnostic Trouble Codes (DTCs),
Description
Go to the Service Action
Code List in Table 2
(Pages 11-14)
M
N
A
M
Q
M
M
I
A
C
A
N
M
