BENDIX AutoVue FLC-20 Service Data page 13

Service
Action
Code
This Diagnostic Trouble Code (DTC) is not an indicator of a malfunctioning camera. Do not
replace the camera.
Possible causes:
• The system using the camera has found J1939 signal(s) it is expecting, however the values
indicate that there is a malfunctioning component and/or wiring error.
• Some examples of components, cameras or switches that produce J1939 signals are: brake
pressure switches; steering angle sensors; lighting indicators (high/low beam lights, turn signals);
windshield wiper status; various engine torque signals; Bendix
System components; and wheel speed sensors.
Perform the following:
N
• Check the engine, cab/body controller, Bendix Wingman Fusion components, or ABS for DTCs
using the manufacturer's diagnostic procedures. The controller that broadcasts the error signal
must be investigated first; however, the origin of the signal could potentially be another source.
After addressing the possible causes, perform the following:
• Clear the camera's DTCs using the procedure in Section 2.18 Clearing Diagnostic Trouble Codes.
If the error returns, see the Bendix Wingman Fusion System (SD-61-4963) Service Data Sheet for
more troubleshooting information, or call the Bendix Tech Team at 1-800-AIR-BRAKE
(1-800-247-2725), option 2. Representatives are available 8:00 a.m.-6:00 p.m. ET, Monday - Thursday,
and 8:00 a.m.-5:00 p.m. on Friday, to assist you.
This Diagnostic Trouble Code (DTC) is not an indicator of a malfunctioning camera. Do not
replace the camera.
Possible causes:
• The Bendix
out of the normal operating range.
Review the following Sections:
• 3.6 Camera Interchangeability.
• 2.13 Serial Data (J1939) Troubleshooting Procedure.
P
Perform the following:
• Check the engine, cab/body controller, or ABS for DTCs using the manufacturer's diagnostic
procedures. The controller that broadcasts the signal indicates that a camera or switch input is
producing a value that is out of the normal operating range.
• After addressing the possible causes, perform the following:
• Clear the camera's DTCs using the procedure in Section 2.18 Clearing Diagnostic Trouble Codes.
If the error returns, call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2.
Representatives are available 8:00 a.m.-6:00 p.m. ET, Monday - Thursday, and 8:00 a.m.-5:00 p.m. on
Friday, to assist you.
Note: The system will not report newly active J1939 DTCs until the engine has been running for 15 seconds.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
Table 2 – Service Action Codes to Recommended Service (Pages 11-14)
AutoVue FLC-20
™ ®
Do not attempt to diagnose J1939 DTCs without the engine running.
Recommended Service
camera finds an expected J1939 source, but the signal's value is
™
Wingman Fusion Active Safety
® ® ™
13
