2.3 CAMERA TEST IMAGE

Take a Test Image Using the Latest Version of Bendix
Troubleshooting a camera may be assisted by viewing a test image from the camera to ensure it is not blocked, or
has another problem.
• Open Bendix ACom
®
ECU" button.
• Select "Snapshot" from the choices.
1. Click "Read". A camera snapshot is
taken. (Approximately 5 minutes.)
2. Inspect the image.
3. Save, if needed, using "Export".
Diagnostic Software and select "FLC-20" from the opening page list, and the "Start with
®
ACom Diagnostic Software
® ®
