3.0 TYPICAL INSTALLATION

The Bendix
AutoVue
FLC-20
®
and the OEM. See Figure 11. (When replacing a camera bracket, temporarily mark the location of the top of the original
bracket to help position the replacement.)
Note: Kenworth
T680/880 and
Peterbilt 579/567
models do
not have a
rubber seal, so
measure down
Line Mark
(at the center
line mark)
from where the
printed "frit"
pattern's solid
black part ends.
During troubleshooting, if you need to check that the camera bracket is installed at the correct point on the
windshield, use the Make/Model columns to find the correct vertical distance "A" (and "B" if applicable).
Vehicle
Vehicle OEM*
Model
T680 / T880 /
W990
Kenworth
®
T370
Mack
CHU / CXU
®
ProStar
LoneStar
Navistar
®
DuraStar
International
®
LT
series,
RH
series
Navistar
®
CE Series
IC Bus
579 / 567
589
Peterbilt
337/348
Volvo
VNM / VNL
18
camera is installed on the windshield at a position determined by Bendix engineering
Top and Center of Windshield - Viewed from Inside.
®
A
Center
Distance "A"
± ⅛ in. (3 mm)
1.4 in. (35 mm)
2.38 in. (60.3 mm)
2 in. (51 mm)
,
®
,
®
,
2 in. (51 mm)
®
7.125 in. (180 mm)
1.4 in. (35 mm)
1.18 in. (30.0 mm)
1.3 in. (34 mm)
* All trademarks shown here are the property of their respective owners and are used for reference only.
A
B
NOTE: Some
Placements
are Offset
Note: Use only Bendix-approved
windshield adhesive when
re-mounting a camera bracket.
(Included with the bracket kit.)
Top Mounting Instruction
Distance "B"
± ⅛ in. (3 mm)
Windshields have a mark at the center line. Measure
0
down from the lower edge of the printed border.
The camera bracket is offset to the passenger's side
of the vehicle by 6 in. (152 mm) from the center. The
6 in. (152 mm)
camera bracket is located 2.38 in. (60.3 mm) downward
from the interior seal of the windscreen.
Measure down from the lower edge of the rubber seal.
6 in. (152 mm)
Note the offset B. The camera bracket is offset to the
passenger's side of the vehicle.
The camera bracket is offset to the passenger's side
6 in. (152 mm)
of the vehicle. Measure down from the lower edge of
the rubber seal. [There is a grey mask area that is
1.8 in. (45 mm) high.]
6 in. (152 mm)
Windshields have a mark at the center line. The
vertical location is between the bracket's uppermost
0
surface and the nearest surface of the windscreen
seal. Measure down from the lower edge of the printed
border.
0
Measure down from the bottom of the windscreen seal.
0
Measure down from the lower edge of the rubber seal.
Torpedo level Angular
tolerance of +/-1º
A small "Torpedo" Level
is Used to Make Sure the
Top of the Bracket is Level
