GJD D-TECT R Ricochet GJD830R Manual

D-TECT R Ricochet
GJD830R Ricochet Enabled Wireless
®
PACKAGE CONTENTS
• 1 x wireless detector
• 3 x wall plug & screw sets
• 1 x lens mask
• 2 x additional curtain shutters
• 1 x tamper cup
• 2 x tamper caps (different lengths)
• 1 x plastic opening tool
• 1 x installation manual
• 1 x drilling template for fixing holes
IMPORTANT INFORMATION: To fully utilize the GJD
D-Tect Unit with Texecom Ricochet Monitoring Software,
please upgrade your monitoring software via the Texecom
website to the Version 2.18.0 or later.
INTRODUCTION
The wireless detector uses a quad pyro where both
sensors must trigger to cause the detector to signal an
alarm ensuring precise and reliable presence detection.
Programmable options include a variable pulse count and
a choice of detection ranges up to 30 meters. The dual-axis
tilt sensor allows 180° of pan and 90° of tilt. This increases
the speed of the outdoor installation and provides accurate
aiming of the detection pattern.
Precision electronics, digital white light filtering, and
double shielding eliminates false alarms from the sun. The
detector housing has a professional appearance with the
sensing module hidden behind the front cover.
QUICK INSTALLATION
1. Place two CR123 batteries into the detector battery
holders. Observe the polarity. See figure 4, item 1.
The detection LED will flash four times.
2. With the Ricochet® expander in commission mode
enter the learning menu on the control panel. To learn
the device follow the instruction given in the control
panel documentation.
3. Press and release the programming button once to
learn the device. ( Fig 10, item 2).This action also
activates walk test mode. Note: The learn process
may take up to 10 seconds from pressing the
programming button. Learn will be confirmed on the
control panel.
4. The detector will take approximately 3 minutes to
settle. The detection LED is now enabled for five
minutes.
5. Mount the detector following the instructions below.
Note: To carry out a walk test the zone mode must be
programmed to be 'Always Awake' and the front cover
must be fitted and secured.
The default settings are:
•Range: 30 meters
•Pulse count: 1
FITTING THE DETECTOR
Protect the electronics against water. Trapped moisture can
affect or damage the unit.
Mounting holes should be sealed from within the detector
using acrylic (non-silicone based) sealants. Silicone
sealants must not be used as vapours may corrode the
electronics and metal parts.
WARNING
• NYLON WASHERS PROVIDED MUST BE USED
WITH SCREWS
• ENSURE CABLE ENTRY AND SCREW HOLES
ARE SEALED WITH WATER BASED SEALANT
• DO NOT USE SILICONE BASED SEALANT
Ensure the detector's field of view is unobstructed.
MOUNTING THE DETECTOR
1. Drill the wall to accept the fixing screws and the
tamper cup (of used). See Figures 1 and 3. A hole-
drilling template is provided.
Notes
• Use the tamper cup on uneven surfaces.
• Optimum height for the detector is 3m. Higher
mounting heights will result in reduced detection
range.
2. Remove the cover assembly using the plastic
opening tool and by loosening the locking screw. See
Figure 2.
3. Screw the unit to the wall. Ensure the tamper pin is
correctly located and the tamper switch is closed.
Two different length tamper feet are provided for
uneven surfaces. The tamper foot is a push-fit see
Figure 1.
4. When the detector is aligned, powered and
programmed:
a. Fit the cover.
b. Loosely tighten the locking screw.
c. Push the two side plastic latches into the base.
d. Tighten the locking screw.
