Owner's Instruction and Operation Manual
Model Number:
DVAG11, DVAG17,
DVAG30
* All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary.
Save These Instructions In A Safe Place For Future Reference.
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use any phone in your building.
•
Leave the building immediately.
•
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
•
If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Please read this manual BEFORE
installing and operating this unit.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE.
© 2020 United States Stove Company, 227 Industrial Park Rd., South Pittsburg, TN 37380
WARNING:
FIRE OR EXPLOSION HAZARD
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon
monoxide, which is known to the State of California to cause
cancer, birth defects, and/or other reproductive harm. For
more information, go to
853277H-1403K
www.P65warnings.ca.gov
Ph. 800-750-2723
Advertisement
Table of Contents
Related Manuals for Ashley DVAG11N
Summary of Contents for Ashley DVAG11N
- Page 1 Owner’s Instruction and Operation Manual Model Number: DVAG11, DVAG17, DVAG30 * All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary. 853277H-1403K Save These Instructions In A Safe Place For Future Reference. WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Page 2 DIMENSIONS MODEL: DVAG11N/ DVAG11L Height 20 (508 mm) Width 27.36 (695 mm) Depth 6.61 (168 mm) Weight lbs. (kg.) 43 (19.5 kg) Type of Burner Atmospheric 20" (508 mm) # of Burners Ignition Piezo-electric ignitor Standard Heating Space 570 (52.9 m...
- Page 3 INSTALLATION CHECKLIST Your Gas Stove should be installed by a qualified installer only. An NFI qualified Installer can be found at www.nficertified.org/public/find-an-nfi-pro/ CUSTOMER SERVICE 1-800-750-2723 ext 5050 Text to 423-301-5624 Email to: Customerservice@usstove.com COMMISSIONING CHECKLIST This Checklist is to be completed in full by the qualified person who installs this unit. Keep this page for future reference.
- Page 4 MASSACHUSETTS RESIDENTS REQUIREMENTS FOR THE SIGNAGE COMMONWEALTH OF A metal or plastic identification plate shall be MASSACHUSETTS permanently mounted to the exterior of the building at a minimum of eight (8) feet above The following requirements reference various grade directly in line with the exhaust vent terminal Massachusetts and national codes not contained for the horizontally vented gas fueled heating the in this manual.
- Page 5 MASSACHUSETTS RESIDENTS referenced “special venting systems” A copy of all installation instructions for all Product instructions shall be included with the appliance or Approved side wall horizontally vented gas fueled equipment installation instructions and; equipment, all venting instructions, all parts lists for venting instructions, and/or all venting design The “special venting systems”...
- Page 6 PRODUCT FEATURES Max. Gas Inlet Min. Gas Inlet Pres. Reg. Settings Input Power * Model No. Pressure inch Pressure inch Manifold inch W.C. Valve Type Btu/Hr. (kW) W.C. (mm. W.C.) W.C. (mm. W.C.) (mm. W.C.) DVAG 11N 11,000 (3.20 kW) 10.5 (267 mm) 7 (178 mm) 5 (127 mm)
- Page 7 INSTALLATION IN S ID T A IL E R D E C O R N F IX E D C L O S A B LE O P E R F IX E D C L O S A B LE O P E R VENT TERMINAL AIR SUPPLY INLET...
- Page 8 INSTALLATION INSTALLING THE APPLIANCE IMPORTANT: Separate the hanging bracket from the appliance INSTALLATION REPAIR SHOULD by removing two screws on the top and two nuts at DONE BY A QUALIFIED SERVICE PERSON. the bottom. APPLIANCE SHOULD INSPECTED BEFORE USE AND AT LEAST ANNUALLY INSTALLING THE HANGING BRACKET BY A QUALIFIED SERVICE PERSON.
- Page 9 INSTALLATION 3. Insert the two provided rubber grommets (v) into the lower bracket as shown in figure 6a. Place the hanging bracket over the square hole. Check to see the bracket is level. After leveling the hanging bracket, mark the four holes as shown in figure 6b.
- Page 10 2 and Figures 7 and 8). Note: Use the heat shield to help hold the bracket in place when marking the square hole locations. TABLE 2 Figure 8 FLOOR DVAG11N / DVAG11L 11-1/4” X 11-1/4” 5. Insert the two provided rubber grommets (v) 9-1/8” 6-13/16” 20-3/16”...
- Page 11 INSTALLATION Remove the hanging bracket and drill the four 2. Use two screws (i) to secure the bottom medium holes using a 3/32” drill bit. bracket to the unit. 8. Place the hanging bracket and fix it with four screws (ii) and four washers (iii). IMPORTANT: The four 1/4”...
- Page 12 INSTALLATION IMPORTANT: Table 3 Lengths Of Pipes And Rod. THE VENT-AIR INTAKE SYSTEM MUST BE Vent-Air Intake Vent Pipe (B) Rod (D) PROPERLY INSTALLED TO ENSURE PROPER Pipe (C) SAFE OPERATION. VENT-AIR Wall Thickness Wall Thickness Wall Thickness INTAKE SYSTEM MUST ALSO BE PROPERLY + 3-3/8“...
- Page 13 INSTALLATION 5. Slide the vent pipe (B) and vent-air intake pipe (C) through the hole in the wall, and connect REQUIRED: them to the appliance flue outlet and air Downward slope intake,respectively. of 1/4” per foot Flush with of venting to the 6.
- Page 14 INSTALLATION GAS CONNECTION WARNING: We recommend using only new black iron or • FOR L.P. GAS, USE PRESSURE REGULATED steel pipe. CHECK LOCAL CODES. GAS SUPPLY. DO NOT DIRECTLY CONNECT 2. The gas supply line shall be sized and installed SUPPLY TANK PRESSURE...
- Page 15 OPERATION WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. damage, personal injury or loss of life. LIGHTING INSTRUCTIONS 1. STOP! Read the safety information on the attached plate. Pliot Burner 2.
- Page 16 OPERATION NOTE: It is normal for the new wall furnace to give The correct flame pattern of pilot and main burner some odor the first time it is burned. This is due to are shown in the provided figures. the curing of the paint and any undetected oil from the manufacturing process.
- Page 17 THERMOCOUPLE Figure 21 Correct pilot burner flame pattern OPERATION PRIMARY FLAME: 1/4´´ - 3/8´´ (6 - 10 mm) Figure 21 SECONDARY FLAME: 2´´ - 4´´ (50 - 100 mm) Figure 20 Correct pilot burner flame pattern Correct main burner flame pattern CLEANING THE MAIN BURNER ORIFICE SECONDARY FLAME &...
- Page 18 TROUBLESHOOTING WARNING: TURN OFF HEATER AND LET COOL BEFORE SERVICING. ONLY A QUALIFIED SERVICE PERSON SHOULD SERVICE AND REPAIR HEATER. WARNING: TURN OFF HEATER AND LET COOL BEFORE SERVICING. ONLY A QUALIFIED SERVICE PERSON SHOULD SERVICE AND REPAIR HEATER. PROBLEM POSSIBLE CAUSE REMEDY Ignitor electrode broken.
- Page 19 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE REMEDY Burner orifice is clogged. Clean burner orifice or replace burner orifice. Burner does not light Burner orifice diameter is too Replace burner orifice. after pilot is lit. small. Inlet gas pressure is too low. Contact local Gas Company. Manifold pressure is too low.
- Page 20 REPLACEMENT PARTS © 2021 United States Stove Company...
- Page 21 REPLACEMENT PARTS Part # Description Model 81311 DVAG11 DVAG11, 81312 Burner DVAG17 81347 DVAG17, 81313 DVAG30 DVAG30 Pilot Assembly DVAG11, 81345 DVAG11, Burner Connection DVAG17 81303 DVAG17, Tube 81346 DVAG30 DVAG30 893236 “Vent Pipe Kit (Includes DVAG11 81342 DVAG11 893237 inner/outer pipe, vent DVAG17 81343...
- Page 22 SERVICE RECORD It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. SERVICE PROVIDER Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. Always use the manufacturer's specified spare part when replacement is necessary.
