2. The servo arms should all be at right angles. You can readjust with the transmitter's trim function. With computer transmitters, this can also
be done using the „sub-trim" or „servo centre" function.
3. By default, the outermost hole of each lever is used, but you can also use the holes further inwards, which will increase the deflections and
make the model more aerobatic.
4. Align the elevator, aileron and rudder in parallel by turning the clevises on the linkages either in or out. The clevises have small pins that
must engage the holes in the levers. Always open and close the clevises with care.
Note: Secure the clevises with a piece of silicone tube to prevent accidental opening.
Querruder
Aileron
Rudder
34
MODSTER Easy Trainer 1280 V2
Höhenruder
Elevator
