Temperature And Adjustment - LINDR PYGMY 30/K prof Instruction Manual

14.2 Speed Fitting Removal
13 c
figure
Hold the grey ring tight against the body of
the speed fitting and pull out the hose.
WARNING: If you do not hold the grey ring but pull at the hose, the speed fitting will cut
even deeper into the hose.
WARNING: Hoses must not be pressurised during removal.

15. TEMPERATURE AND ADJUSTMENT

The temperature of the cooled beverage is controlled by a mechanical thermostat in
temperature range of 2 °C to 8 °C.
The thermostat has a numerical scale of 1-7.
13 b
figure
0 = OFF
WARNING: If you are using the cooler to cool non-alcoholic beverages, set the thermostat
knob to 5 at the most, otherwise, there is a risk of the beverage freezing in the cooler's tubing
and damaging the device.
13 c
figure
1 = MAX. BEVERAGE
TEMPERATURE (8°C)
13 d
figure
7 = MIN. BEVERAGE
TEMPERATURE(2°C)
13
