LINDR PYGMY 30/K prof Instruction Manual page 28

Flow-through contact cooler
Table of Contents

Advertisement

Available languages

Available languages

8 A
figure
8 c
figure
CHECK VALVE
WARNING: Before you screw the speed fitting onto the 5/8" thread, make sure the keg
8
coupler (air inlet for delivery medium) has a lip valve (check valve) fitted on it.
11.2 Outlet for Beverage
Screw an F 5/8" x 3/8" (9,5 mm) speed fitting onto the keg coupler.
5/8"-5/16(8mm)
8 b
figure
8 d
figure
5/8"-3/8"(9,5mm)
