ASSEMBLY INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
3b. With deck plate installation: Place a bead of
clear silicone sealant (not included) around the
base of the putty plate (F). Place putty plate (F)
and deck plate (E) on sink (not included). Insert
faucet body (B) through deck plate (E).
4.
Unscrew preassembled screws on lock nut
(I) until they are flush with the face of the
lock nut (I).
5.
Slide rubber washer (G) and metal washer
(H) onto shank of faucet body (B). Secure
faucet body (B) to sink with lock nut (I) and
preassembled screws.
3b
3b
F
1
4
4
I
5
5
B
G
H
I
5
E
B
2
2
5-1
5-2
1
2
3
