GBC ORCA 64TH Schematics

GBC ORCA 64TH Schematics

Illustrated parts and schematics book
Hide thumbs

Advertisement

Quick Links

Download this manual
GBC ORCA 64 TH
ILLUSTRATED PARTS
AND SCHEMATICS BOOK
Illustrated Parts
Electrical Schematics
07/11/03

Advertisement

loading
Need help?

Need help?

Do you have a question about the ORCA 64TH and is the answer not in the manual?

Questions and answers

Related Manuals for GBC ORCA 64TH

Summary of Contents for GBC ORCA 64TH

  • Page 1 GBC ORCA 64 TH ILLUSTRATED PARTS AND SCHEMATICS BOOK Illustrated Parts Electrical Schematics 07/11/03...

  • Page 2: Illustrated Parts

    ILLUSTRATED PARTS Page O64TH - 001 Frame Assembly O64TH - 002 Rewinder Assembly O64TH - 003 Rollers & Sensor Assembly O64TH - 004 Front & Rear Table Assembly O64TH - 005 Chain Linking Assembly O64TH - 006 Main Roller Lift Assembly O64TH - 007 Safety Shield Assembly O64TH - 008...
  • Page 3 (2) 601220347 Cross Bar PCB Bracket (4) 701130504 5" Caster (4) 601220364 Leveling Foot This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL. SHOWN 4151 Anderson Road, DeForest, WI 53532...
  • Page 4 Rewinder Shaft See O64TH - 014 Detail "A" (3) 613020073 Rewinder Shaft Holder (3) 613020074 This print is the property of GBC. The information thereon is remitted in confidence. Rewinder Shaft Holder Support UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL.
  • Page 5 Thermal Sensor Bar See O64TH - 012 (1) 607050121 Upper Heat Roller (1) 607050119 Lower Heat Roller This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL. SHOWN...
  • Page 6 Front Table Bracket, Left Front Table Support Bracket (2) 704090419 (1) 601410748 Micro Switch Micro Switch Cover This print is the property of GBC. The information thereon is remitted in confidence. (1) 604036235 UNLESS OTHERWISE SPECIFIED TOLERANCE Micro Switch Lever DIM. AS FINISH TOL.
  • Page 7 Washer (?) ????????? Steel Chain Gear, ??T (?) ????????? Washer (?) ????????? Ball Bearing This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL. SHOWN 4151 Anderson Road, DeForest, WI 53532...
  • Page 8 Upper Heat Roller Bearing Housing Plate (2) 601220344 (2) 601220304 Interruptor Plate (8) 703070286 Lower Guide Support Speed Controller This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL. SHOWN...
  • Page 9 (1) 601410831 Safety Cover Lever (1) 604036238 Safety Cover Cap, Lower (1) 701090169 Lever Spring This print is the property of GBC. The information thereon is remitted in confidence. (1) 604022109 UNLESS OTHERWISE SPECIFIED TOLERANCE Table Lever Guide DIM. AS FINISH TOL.
  • Page 10 (1) 703020230 Control Key, Square (1) 703020229 Control Key, Rectangle (1) 803040530 Control Panel Over Lay This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL. (1) 703020231...
  • Page 11 Fuse Holder (Not Shown) (1) 704130117 Fuse, 20mm/ 250V/ 3.15A (Not Shown) (1) 704130118 This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED Fuse, 20mm/ 250V/ 4.0A (Not Shown) TOLERANCE DIM. AS FINISH TOL.
  • Page 12 Heater Support Bar Bracket (2) 601220369 Heater Support Bracket, Upper (4) 601220334 Heater Support (2) 601410757 Heater Support Cover This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL. SHOWN...

  • Page 13: Upper Idler

    Idler Roller Cover (2) 601220321 Idler Roller Pin (9) 701010141 Ball Bearing, #6902 (2) 601410737 Channel Cover This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL. SHOWN...
  • Page 14 (2) 613020675 701020213 Tension Block, Lower 604020425 Lower Rewinder Sprocket Assembly (2) 601220670 Tension Stopper, Lower This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL. SHOWN 4151 Anderson Road, DeForest, WI 53532...

  • Page 15: Assembled View

    Thrust Needle Roller Bearing Washer (1) 613020658 Film Pipe Bracket, Lower Left (1)613020673 Film Pipe Bracket, Lower Right This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL.
  • Page 16 (1) 703070284 Solenoid Valve, SY7220-6G-02 (4) 703070287 Fitting, KQ2H08-02S-X2 703070287 (2) 703070290 Silencer, AN203-02 This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL. SHOWN 4151 Anderson Road, DeForest, WI 53532...
  • Page 17 PCB Plate (1) 601410778 Side Plate, Right (1) 601410777 Side Plate, Left (1) 601410783 This print is the property of GBC. The information thereon is remitted in confidence. Side Cover, Lower, Left UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL.
  • Page 18 (1) 706111049 Back Trimmer Assembly (See Detail "A' for break down of parts) (1) 601410766 Blade Rail Bracket, Left This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL.
  • Page 19 COPIED OR DISCLOSED IN WHOLE OR IN PART, OR USED FOR MANUFACTURE OR FOR ANY OTHER PURPOSE WITHOUT WRITTEN PERMISSION FROM GBC. This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM.
  • Page 20 DRV_C SW_C I_SEN SW_E POWER CN12 CMP- NJM2360 POWER This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL. SHOWN 4151 Anderson Road, DeForest, WI 53532 TO BE...
  • Page 21 10/16 104J 10/16 MAIN_MOT 74HCT04AN U1/E 74HCT04AN U1/F 74HCT04AN This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL. SHOWN 4151 Anderson Road, DeForest, WI 53532 TO BE...
  • Page 22 +15V ADFB_SPD +15V MOT_PWM 100/50 MOT_REV MAIN_MOT ADFB_FAN FAN_PWM This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL. SHOWN 4151 Anderson Road, DeForest, WI 53532 TO BE...
  • Page 23 LED_SPEED ST4094 LED_MODE 14584 U2/E 14584 U2/F 14584 74HC4094 This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL. SHOWN 4151 Anderson Road, DeForest, WI 53532 TO BE...
  • Page 24 D-10 REL-CH2 D-10 CN10 100R CN11 BEAM_SIG 4.7K MCU_SIG This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL. SHOWN 4151 Anderson Road, DeForest, WI 53532 TO BE...
  • Page 25 FOOTSW_ON USSR ADL_TEMP U_SSR TABLE FOOTSW RESET U_SSR L_SSR This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED TOLERANCE DIM. AS FINISH TOL. SHOWN 4151 Anderson Road, DeForest, WI 53532 TO BE...
  • Page 26 R130 R131 SYNC_MOT_R 330F 100F TRI108 BTA08B Q108 R132 This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED MOC3043 TOLERANCE DIM. AS FINISH TOL. SHOWN 4151 Anderson Road, DeForest, WI 53532 TO BE...
  • Page 27 +15V 74HCT04AN U1/E POWER 10/16 74HCT04AN U1/F 10/16 104J This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED 74HCT04AN TOLERANCE DIM. AS FINISH TOL. SHOWN 4151 Anderson Road, DeForest, WI 53532 TO BE...
  • Page 28 The GBC Engineering Team has released an Electronic Upgrade Kit part number 005187 that must be installed on all Orca 64TH’s that experience problems related to the Main P.C. Board, Motor Driver P.C. Board, and Vacuum Fan Driver P.C. Board. This Electrical Upgrade Kit is replacing the Vacuum Driver P.C.
  • Page 29 14 - Mark all wires to the main control PCB and swap the old board with the new one in the kit. KEEP Noise Filter, 15A Aluminum Heat Sink This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED Industrial & Print TOLERANCE Finising Group DIM.
  • Page 30 22 - Connect the upper Resistor to the main motor PCB cn8 p_res Phoenix Relay 1 This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED Industrial & Print...
  • Page 31 26 - Connect the kit wires labeled “Motor Driver Board DC1” to the motor driver board DC1 socket. These wires originate at the 48 volt power supply termi nals +V and -V . This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED Industrial & Print...
  • Page 32 35 - Reinstall the electronics area metal cover box. It may be necessary to flex the bottom open outward a bit. 36 - Reinstall machine side panel(s). Test all functions once again. Finished. This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED Industrial & Print...

  • Page 33: Power Supply

    Relay board motor Power resistor 48V DC 07/24/2006 Power supply 200W This print is the property of GBC. The information thereon is remitted in confidence. input UNLESS OTHERWISE SPECIFIED Industrial & Print TOLERANCE Finising Group DIM. AS FINISH TOL. 6175 E. Metro Dr. DeForest, WI 53532...

  • Page 34: Vacuum Fan

    24V DC Power supply 200W Vacuum Fan Phoenix Omron 07/24/2006 This print is the property of GBC. The information thereon is remitted in confidence. UNLESS OTHERWISE SPECIFIED Industrial & Print TOLERANCE Finising Group DIM. AS FINISH TOL. 6175 E. Metro Dr. DeForest, WI 53532...
  • Page 35 The heater wire and brass connector can now be attached onto the end of the heater. 500 Bond Street • Lincolnshire, IL 60069 • ph 800-723-4000 • fax 888-821-3736 • www.gbc.com...
