  • Page 1 Speech Transfer System STS-K020 Installation & User Guide December 2019...

  • Page 2: Table Of Contents

    Contents Product Overview Installation Instructions Amplifier Installation Customer Microphone Installation Customer Speaker Installation Staff Speaker & Microphone Installation Hearing Loop Installation Amplifier Setup Using the System Troubleshooting Contacta has a policy of continuous product development, and therefore small specification changes may not be reflected in this manual. Images, labels, packaging, accessories and product colors are subject to change without notice.

  • Page 3: Product Overview

    Product Overview Contacta’s STS-K020 may be retrofit to glass with the opening from an existing system. This product is designed for installation at locations such as banks, post offices, theaters, and more. A hearing loop aerial is included to provide additional assistance for hearing device wearers. Features • Excellent sound quality • ADA conscious • Level 3 ballistic rated • Sleek and modern design...

  • Page 4: Amplifier Installation

    Amplifier Installation STS-A31H Speech Transfer System Amplifier 1. Place the amplifier under the staff counter, ensuring that it will not obstruct staff when they are sitting. Fixing points 2. Take note of the cable management path. 3. Mark the four fixing points for the amplifier under the counter. 4. Drill and fix the amplifier in place using the supplied screws. 5. Please take note of the cable management path at this time...

  • Page 5: Customer Microphone Installation

    Customer Microphone Installation STS-C100 Anti-Vandal Microphone with Glass Mount Kit 1. Separate the front and rear polycarbonate plates. 2. Feed one silicon gasket through the wire connected to the front (customer-facing) polycarbonate plate. 3. Align the holes in the silicon gasket and the front polycarbonate plate. Screw an 8-32 2” stud into every other hole (three total) to temporary hold the alignment. 4. While standing on the customer-side, feed the wire cable attached to the front polycarbonate plate through the opening of the glass barrier. 5. Hold the front polycarbonate plate flush to the opening in the glass barrier and use tape to temporary secure the front polycarbonate plate to the window.
  • Page 6 down based on the glass barrier’s thickness. 11. Put three of the 8-32 2” screws into the remaining holes in the plate, screwing in enough to hold all pieces together. 12. Remove the alignment studs and replace with the remaining three 8-32 2” screws. 13. Tighten the screws in a “star” configuration, tightening each screw in small increments until all screws are completely tightened. 14. Secure the tubing in place. 15. Plug the wire’s connector into the “Cust Mic” port on the back of the amplifier. Note: The RED wire should be on the RIGHT side of the connector.

  • Page 7: Customer Speaker Installation

    Customer Speaker Installation Option 1: STS-S30 Surface Mounted Speaker (Overhead Installations) The optimum installed height of this speaker is 6-8 feet from the customer. Environments with more background noise may require a lower installation. 1. Unscrew the four screws on the sides of the speaker housing. 2. Remove the back plate from the speaker housing. 3. Find a location on the customer side directly above the glass barrier where interactions will take place. Ensure there is enough space to drill and there is no glass behind the material. 4. Check the cable route to the amplifier location under the counter, noting cable length and access through the countertop. 5. Mark the fixing points to mount the back plate while ensuring there is access to retrieve the cable. 6. Drill fixing points using a drill bit smaller in diameter than the screws that will be permanently installed.
  • Page 8 11. Plug the speakers’ connector into the “Cust Spkr” port on the back of the amplifier.
  • Page 9 Option 2: STS-S22 Bracket Mounted Speaker (Overhead Installations) The optimum installed height of this speaker is 6-8 feet from the customer. Environments with more background noise may require a lower installation. 1. Find a location on the customer side directly above the glass barrier where interactions will take place. Ensure there is enough space to drill and there is no glass behind the material. 2. Check the cable route to the amplifier location under the counter, noting cable length and access through the countertop. 3. Mark the fixing points to mount the speaker bracket while ensuring there is access to retrieve the cable. 4. Drill fixing points using a drill bit smaller in diameter than the screws that will be permanently installed. 5. Align the speaker bracket with the fixing points. 6. Mount the back plate using the appropriate screws/fixings. 7. With the cable facing down, slip the bolts on the side of the speaker into the groves of the bracket. Adjust position of speaker and tighten bolts to secure in place.
  • Page 10 Option 3: STS-S60 Surface Mounted Speaker (Counter Installations) 1. Place the speaker on the customer side of the countertop. 2. Unscrew the two screws on the sides of the speaker housing. 3. Remove the bracket from the back of the speaker housing. 4. Place the housing bracket on either side of the point of interaction between the staff and customer, at least 2-3mm away from the glass barrier. 5. Mark two fixing points and one cable management hole to mount the housing bracket while ensuring there is access to retrieve the cable. 6. Drill fixing points using a drill bit smaller in diameter than the screws that will be permanently installed, then drill the hole for the speaker cable. Housing fixing points Cable hole Fixing points 7. Align the housing bracket into position. Feed the wire through the cable hole.
  • Page 11 8. Connect the speaker housing to the bracket with the previously removed screws. 9. Route all cabling neatly to the amplifier location on the staff side. 10. Plug the speakers’ connector into the “Cust Spkr” port on the back of the amplifier.
  • Page 12 Option 4: STS-S61 Flush Mounted Speaker (Wall/Counter Installations) 1. Ensure there is at least 2 inches of free space below the customer side of the countertop for the speaker pod. 2. Ensure there is access to the wiring under the counter once installed. 3. Mark the cut-out dimensions in the diagram below onto the countertop. 4. Use a router to cut out two areas for the flush mounted speaker pod. 5. Cut Area 1 in diagram to a depth of 1 7⁄8”. 6. Cut Area 2 (shaded) in diagram to a depth of 1.5mm. 7. Cut corner radius to R6 in Area 2.
  • Page 13 8. Mark the four fixing points as shown in the diagram below. Drilled fixing points Speaker pod container cut-out 9. Drill fixing points using a drill bit smaller in diameter than the screws that will be permanently installed. 10. Run the cable from the speaker through the countertop. 11. Secure speaker to the counter using the screws provided. Fixing points 12. Route all the cabling neatly to the amplifier location on the staff side. 13. Plug the speakers’ connector into the “Cust Spkr” port on the back of the amplifier.

  • Page 14: Staff Speaker & Microphone Installation

    Staff Speaker & Microphone Installation Option 1: STS-SU1 Staff Unit 1. Place the staff unit on the staff side of the countertop, ensuring that it does not cause an obstruction and is as close to staff as possible. 2. Use the cable management hole in the counter to run the staff microphone cable back to the amplifier. If there is not already a cable management hole, drill one (or at least a ½ inch hole) in a suitable location near the rear of the counter. 3. Plug the unit’s connectors with BLACK and YELLOW wires into the “Staff Spkr” port on the back of the amplifier. Note: The BLACK wire should be on the LEFT side of the connector. The YELLOW wire should be on the RIGHT side of the connector. 4. Plug the unit’s connectors with BLACK+WHITE and RED wires into the “Staff Mic” port on the back of the amplifier. Note: The BLACK+WHITE wires should be on the LEFT side of the connector. The RED wire should be on the RIGHT side of the connector.
  • Page 15 5. The staff unit can be turned on by flipping the switch. When pressed down, the “O” position indicates the unit is OFF, and the “I” position indicates the unit is ON.
  • Page 16 Option 2: STS-SJB Break Out Box with STS-Headset 1. The Break Out Box should be installed underneath the counter using the screws provided. Ensure it is placed in a convenient location for the staff to access the mute button while being mindful of the headset cable length and the position of the staff member. 2. Plug the unit’s connectors with BLACK and YELLOW wires into the “Staff Spkr” port on the back of the amplifier. Note: The BLACK wire should be on the LEFT side of the connector. The YELLOW wire should be on the RIGHT side of the connector. 3. Plug the unit’s connectors with BLACK+WHITE and RED wires into the “Staff Mic” port on the back of the amplifier. Note: The BLACK+WHITE wires should be on the LEFT side of the connector. The RED wire should be on the RIGHT side of the connector. 4. Connect the headphone’s two audio jacks to the front of the Break Out Box in their corresponding ports. 5. To use the headphone and microphone, ensure the mute button on the...
  • Page 17 front of the Break Out Box is not pressed in. To mute, press the button in. 5. OPTIONAL: The STS-SU1 Staff Unit may also be connected to the Break Out Box, giving staff member’s the option to use either the standing unit or the Break Out Box with headset. 1. Microphone port 2. Speaker port a. Plug the staff units’ connectors with BLACK and YELLOW wires into the “Staff Spkr” port on the back of the Break Out Box. Note: The BLACK wire should be on the LEFT side of the connector. The YELLOW wire should be on the RIGHT side of the connector b. Plug the staff units’ connectors with BLACK+WHITE and RED wires into the “MIC” port on the side of the Break Out Box. Note: The BLACK+WHITE wires should be on the LEFT side of the connector. The RED wire should be on the RIGHT side of the connector. c. To use the STS-SU1 Staff Unit, ensure the mute button on the side of the Break Out Box is not pressed in and the Staff Unit and Speaker’s switch is in the ON position. To mute, press the mute button on the Break Out Box.

  • Page 18: Hearing Loop Installation

    Hearing Loop Installation Ensure all hearing loop signage is displayed clearly. Option 1: IL-AE96 Window Mount Hearing Loop The IL-AE96 Window Mount Hearing Loop should be installed indoors on the staff side. 1. Determine the location of the hearing loop aerial on the glass barrier. Make sure to place it directly in front of where a customer will stand. It is recommended that the unit is placed on the bottom corners of the glass barrier for optimal performance. Do not exceed 2 feet above the average standing customer. 2. Clean the area with a glass cleaner and thoroughly wipe dry. 3. Remove the liner on the blue sheet with a faint outline of the international hearing loop signage to expose the adhesive backing. Please note that both sheets are not solid blue. 4. Carefully attach the sheet on the glass barrier with the international hearing loop signage facing the customer. Slowly apply to glass barrier while smoothing out air bubbles with straight-edged tool.
  • Page 19 6. Carefully apply the hearing loop aerial with attached cable to the adhesive on the solid blue sheet. Ensure the cable is at the edge of the sheet, and the wire is coming from the back side of the aerial when applied. 7. Attach the solid blue sheet with hearing loop aerial to the sheet attached to the glass barrier. Slowly apply while smoothing out air bubbles with straight-edged tool.
  • Page 20 Option 2: Under the Counter Hearing Loop 1. The aerial should be fixed under the desk or counter centrally on the customer side, one half mounted horizontally under the counter and the other half mounted vertically, facing the customer (see A in the diagram below). Position the aerial under the counter using either the provided P-clips or another fixing method of choice. See the diagram below for recommended positioning.  A is the optimum layout for a counter hearing loop. B and C are acceptable only if A is not possible and the layout is aligned so that the magnetic field will be directed towards user’s head heights. 2. Route the cabling neatly to the amplifier location on the staff side 3. Plug the loop’s connector into the “Loop” port on the back of the amplifier.

  • Page 21: Amplifier Setup

    Note: Ducking Adjustment and Hearing Loop Drive Adjustment should be kept at factory default levels (see page 26) in the majority of circumstances. If adjustments to either setting are required, please seek consultation from Contacta’s technical department. Maximum Volume Adjustment – Adjust the maximum volume level the • amplifier delivers to both customer and staff side speaker outputs. This feature is to prevent staff members users from increasing the volume to the point where audio feedback occurs.
  • Page 22 feedback. The Ducking Adjustment setting determines how much volume variation the ducking can utilise between the two sides. Sound quality can be compromised if an excessive amount of ducking is used. Hearing Loop Drive Adjustment – Increase or decrease the strength of • the installed hearing loop’s magnetic field. The drive level should be adjusted so that red LED 8 on Vol Out is illuminated only when there are peaks in the speech volume (see diagram on following page). Entering Engineer’s Mode Before entering engineer’s mode, cycle the power. To do this either: • Switch the power off at the wall socket and back on again, • Remove the power connector and re-insert it To enter engineer’s mode, simultaneously press and press and quickly release the following buttons within 20 seconds of cycling the power: •...
  • Page 23 Setup Areas When in engineer’s mode, there are 3 editable setup areas. You will always enter setup area 1 first. The adjustable setup modes are indicated by the green Volume In LED bar, which will flash to indicate which setup area is active (Maximum Volume Adjustment: 1, Ducking Adjustment: 2, and Hearing Loop Drive Adjustment: 3). Setup Area 1: Maximum Volume Adjustment (Vol In LED 1 flashes) Increase maximum Increase maximum staff volume level customer volume level Decrease maximum Decrease maximum customer volume level staff volume level...
  • Page 24 Setup Reminder: Move to the next setup area by pressing the settings button. Move to the next setup area • When you enter engineer’s mode, you will automatically start in Setup Area 1 (Maximum Volume Adjustment). • By pressing the settings button one time, you will move to Setup Area 2 (Ducking Adjustment). • By pressing the settings button two times, you will move to Setup Area 3 (Hearing Loop Drive Adjustment). • By pressing the settings button three times, you will start back at Setup Area 1 (Maximum Volume Adjustment) and continue to repeat the pro- cess. Press the on/off button to save and exit engineer’s mode. Please note that the amplifier will automatically exit Engineer’s Mode without saving if no buttons are pressed for 2 minutes. For best performance: 1. Enter Setup Area 1. 2. Ensure the customer and staff volumes are turned completely down.

  • Page 25: Using The System

    Using the System When powered and in normal operational mode the amplifier will display Volume In LED 1 as steady green. When the amplifier is switched off using the On/Off button, audio is muted and LEDs are not illuminated; press any button to turn the amplifier on again. To adjust the staff volume level: • Press and hold the Volume In (+) or (-) buttons to increase or decrease the level. The corresponding LED bar will show the volume setting. To adjust the customer volume level: • Press and hold the Volume Out (+) or (-) buttons to increase or decrease the level. The corresponding LED bar will show the volume setting. Final Checks • The staff microphone is best positioned no more than 1 foot from the staff member. Staff • Check the amplifier is fully functional by microphone ensuring the red ‘fault’ light is NOT displaying. If there is insufficient volume even after volume controls have been adjusted, enter engineer’s mode and raise max volume settings. Exit engineer’s mode and repeat initial setup.
  • Page 26 Factory Default Settings To return the amplifier the factory default settings: 1. Unplug the power supply and then reconnect it. 2. Press the On/Off button and Volume In (-) button together then quickly release. 3. The Volume In LED bar will have all LEDs illuminated, while the Volume Out LED bar will display the firmware revision number in a fixed pattern of LEDs. This indicates that default settings have been restored.

  • Page 27: Troubleshooting

    2) Microphone positioned too close 2) Move the microphone to a to speaker. location further from the speaker. 1) Ambient noise in area is too high. 1) Switch off any air con systems, Unit does not desktop fans and or computers to go into power reduce ambient noise. saving mode. If no action is successful please seek assistance from your distributor or a Contacta installer.
  • Page 28 Local dealer: US & Canada +1 616 392 3400 info@contactainc.com contactainc.com...
