- Page 1 ELECTRIC BOLT LOCKS AR-1203L SERIES (Fail-Safe)(Power to Lock) INSTALLATION INSTRUCTIONS RoHS AR-1203L Ver.01-091025 Patent No. M 329084...
- Page 2 Contents I. Order Information ........1 II. Specifications ........... 1 III. Wiring Diagram .......... 1 IV. Contents ..........1 V. Assembly materials ........1 VI. Power input setting A. 12VDC input setting ......... 2 B. 24VDC input setting ......... 2 VII.
- Page 3 SOYAL AR-1203L Installation Manual Technology Co., Ltd. www.soyal.com I. Order Information ∨ 1. Whole alloy housing ∨ 7. Auto-detective logical ∨ 2. Dual Voltage: 12V / 24VDC(By 4-pin jumper) ∨ 8. Lock status sensor output (LSS) ∨ 3.Timer Setting: 0, 3, 6, 9 sec. for door locking ∨...
-
Page 4: Installation Diagram
SOYAL AR-1203L Installation Manual Technology Co., Ltd. www.soyal.com VI. Power input setting B. 24VDC input setting: A. 12VDC input setting: Jumper setting as shown on below: Jumper setting as shown on below: PIN-1 and PIN-2 closed PIN-2 and PIN-3 closed... - Page 5 SOYAL AR-1203L Installation Manual Technology Co., Ltd. www.soyal.com Tem-L Fig. 1 × × × A : 195 27.4 mm B : 155 27.4 mm C :202 34 mm 44.45(1-3/4") CTSK CTSK × × 1. Template-L: Paste up on the doorframe surface before making a mortise cutout.
- Page 6 SOYAL AR-1203L Installation Manual Technology Co., Ltd. www.soyal.com Fig. 6 1. Tem-F: Paste up on the door-side surface before making a mortise cutout. (Tem-F: Place-B is a strike-plate) 2. Fig.4: The reference diagram of installation_4 (Wood door-Dimensions) 3. Fig.5: The reference diagram of installation_5 (Suitable for Metal door) 4.
