Soyal LK1201A Quick Start Manual

SOYAL
ACCESS CONTROL SYSTEM

Feature

The electric bolt lock, AR-1201A(-3) Fail Safe and "AR-1201P(-3) Fail Secure, featured with aluminum
alloy housing is able to dissipate the heat effectively. It supports door status sensor and bolt position
sensor functions. When the bolt is pried, it will send out alarm signal. One LED indicator will show the bolt
position (Red: Unlocked / Green: Locked / Yellow Flashing: Bolt was damaged or pried)

Installation

1. Please note the distance between the lock body and striker plate should NOT over 8mm; otherwise,
the bolt might not drop properly.
2. Installation Diagram (Please refer to the next page)
3. Operation delay time: 0 / 3 / 6 / 9 sec. (Default: 3 sec.)

Wires

Specification

Voltage Optional
AR-1201A(-3)
Fail Safe
Current Draw
AR-1201P(-3)
Fail Secure
Operating Temp. 0~50℃
Door Opened Black Wire (Controller) and Yellow Wire
by (Lock Exist PB)
Indicator Bi-Color LED
Bolt Status
Stand-by (Power to lock)
Delay Time Action
Locked Well
Fail to Lock
Keep Locking
Forced Entry (Alarm)
Remote Release (Exit PB) LED lights up Red

Troubleshooting

1. After "Fail to lock", the bolt will enter into "Keep locking" mode and re-lock twice every 5 seconds.
Users can push the door in the right position, and the bolt will automatically extend and locked.
2. Please check V(+) and V(-) wiring when LED doesn't light up.
3. If the bolt projects but chatters, please check whether the power supply is less than 1000mA
too low.)
(Voltage
®
LK1201A/P(-3) Fail Safe/Fail Secure
12VDC 24VDC
Switch on 900mA 500mA
Normal on 350mA 180mA
Switch on 700mA 500mA
Normal on 170mA 180mA
LED Indicator
LED lights up Red
LED flashes Red once every 0.5 sec
LED lights up Green
LED flashes Red once every 0.5 sec
LED flashes Red once every 0.5 sec
LED flashes Yellow once every 0.5 sec
Electric Bolt Lock
1 2
0 Sec 3 Sec 6 Sec
Red +12V or +24V
Black 0V
Yellow PB
Blue COM
White N.O.
Gray N.C.
Orange N.O.
Green N.C.
AR-1201A/P
Face
Fail Safe/Secure
Plate
AR-1201A/P-3
(mm)
Fail Secure/Secure
AR-1201A/P
Striker
Fail Safe/Secure
Plate
AR-1201A/P-3
(mm)
Fail Secure/Secure
Bolt (mm) 16 (Diameter) x 16 (Throw)
1201A(-3) Status 1201P(-3) Status
Door
Off
On
On
On
On
On
Off
V+
V- (CTL N.C.)
Exit PB
Door Sensor
Door Status
Alarm Input
Bolt Status
205L x 32W x 43H
200L x 32W x 43H
104L x 25.5W x 5H
Lock Door
Off Off
Off On
Off N/A
Off N/A
On N/A
On N/A
Off N/A
GND
Lock
Off
Off
N/A
N/A
N/A
N/A
N/A
