Terex Genie Z-34/22 IC Service And Repair Manual page 9

July 2021
Part No. 1312294GT
Primary Boom Components .............................................................................. 29
4-1 Cable Track .................................................................................................... 29
How to Repair the Primary Boom Cable Track ............................................... 29
4-2 Primary Boom ................................................................................................ 29
How to Shim the Primary Boom ...................................................................... 29
How to Remove the Primary Boom ................................................................. 30
How to Disassemble the Primary Boom ......................................................... 32
4-3 Primary Boom Lift Cylinder ............................................................................ 33
How to Remove the Primary Boom Lift Cylinder ............................................. 33
4-4 Primary Boom Extension Cylinder ................................................................. 34
How to Remove the Primary Boom Extension Cylinder ................................. 34
4-5 Platform Leveling Master Cylinder ................................................................. 36
How to Remove the Platform Leveling Master Cylinder ................................. 36
Secondary Boom Components ......................................................................... 37
5-1 Secondary Boom ............................................................................................ 38
How to Disassemble the Secondary Boom ..................................................... 38
5-2 Secondary Boom Lift Cylinders ...................................................................... 41
How to Remove the Secondary Boom Lift Cylinders ...................................... 41
Engines ................................................................................................................ 43
6-1 Kubota Diesel Models .................................................................................... 43
Timing Adjustment .......................................................................................... 43
How to Check the Glow Plugs ......................................................................... 43
RPM Adjustment ............................................................................................. 43
How to Remove the Flex Plate........................................................................ 44
How to Install the Flex Plate ............................................................................ 44
Coolant Temperature and Oil Pressure Switches ........................................... 44
Z ® -34/22 IC
Table of Contents
ix
