3. ELECTRICAL CHARACTERISTICS

3.1 LCD Panel
3.1.1. Type
3.1.2. Pixel structure
3.1.3. Gray scale
3.1.4. Surface treatment
3.1.5. Backlight
3.1.6 Pixel Faults
Pixel Faults type
Type1 Bright Pixels (Note 1)
Type2 Dark Pixels (Note 2)
Type3 Fault Pixels / Sub-Pixels(Note 3)
Pin 1 Red
Pin 2 Green
Pin 3 Blue
Pin 4 No Connection
Pin 5 Ground
Pin 6 R Return
Pin 7 G Return
Pin 8 B Return
17" diagonal, SXGA resolution, color TFT-LCD
R/G/B sub-pixels in vertical stripes
1280 x 1024 array matrix
A-Si TFT active matrix
16 million Colors.
3H hard coating ,anti-static
Integral CCFT ,
Type to support field replacement.
Life time 30000 hours @ 25C, 50% of initial value.
Model
Project
-5-
Service Manual
S720
Pin 9 DDC +5V
Pin 10 Ground
Pin 11 Ground
Pin 12 SDA
Pin 13 H. Sync &
Composite sync
Pin 14 V. Sync
Pin 15 SCL
S720
LIS17S24KA
≦ 5
≦ 5
≦ 3
