FACTORY PRESET TIMINGS

This timing chart is already preset for the TFT LCD analog display monitors.
Timing
IBM VGA 640x350
IBM VGA 720x400
IBM VGA 640x480
VESA 640x480
VESA 640x480
VESA 800x600
VESA 800x600
VESA 800x600
VESA 1024x768
VESA 1024x768
VESA 1024x768
Horizontal Horizontal
Polarity Frequency
+ 31.47 KHz
- 31.47 KHz
- 31.47 KHz
- 37.86 KHz
- 37.50 KHz
+ 37.88 KHz
+ 48.08 KHz
+ 46.88 KHz
- 48.36 KHz
- 56.48 KHz
+ 60.02 KHz
7
Service Manual
LJE15XE(S500)
Vertical Vertical
Polarity Frequency
- 70.09 Hz
+ 70.08 Hz
- 59.94 Hz
- 72.81 Hz
-
75.00 Hz
+ 60.32 Hz
+ 72.19 Hz
+ 75.00 Hz
- 60.00 Hz
- 70.07 Hz
+ 75.03 Hz
