Features

The S500 are world class TFT LCD analog display monitor that includes the following features.
1. Digital On Screen Display Controls
User friendly buttons [Menu， Select (▲ / ▼)， Auto， Power and hot key (Smoothing，
Auto-Contrast， Auto-Sync)] allowing for picture perfect quality。 User can define display
mode or reset to default settings。 Help menu contains ﹕ Auto-Tune (Adjusting)﹔Color
(9300/6500/User)﹔Quality (Size/Phase/Focus /Dithering)﹔Position (Image
H-Pos./V-Pos./Center) & Position (OSD H-Pos./V-Pos./Center)﹔Language
(English/Germany/French/Spanish/Italian)﹔ Recall (Yes/No)。
2. Power Supply Support
Ability to accept voltages from 100~120 Vac，200~240 Vac,50/60 Hz (+6%,-10%) thus
allowing a full range of input AC power supply。
3. Power Saving System
This monitor will meet the low power specification，Including USA governmental requirements
for Energy Star，the NUTEK standard and the VESA DPMS standard which detected the
Hori/Vert。 Sync signal from host CPU。A dual color(green/amber) LED is located on the front
bezel to indicate the power management states。
4. Frequency Range
Monitor can support video standards from VGA to XGA， where Horizontal frequency
ranges from31~60kHz and Vertical frequency ranges from 58~75 Hz。
