Bergstrom NITE Before You Start

Table of Contents

Download this manual

Before You Start

This model truck requires the blower orientation

to be changed before installation.

Please follow the following steps to change the

blower orientation from side discharge to top

discharge. You may also reverse these directions

to change the orientation from top to side.

Remove Screws

From Top Cover

Remove all the screws

that are holding the top

cover in place. Also

remove the small cover

plate that is attached to

the center of the cover.

This small plate will be

used in step #13.

Bergstrom, Inc. 2390 Blackhawk Road ● P.O. Box 6007 ● Rockford, IL 61125 ●

ATTENTION:

● 1-866-204-8570

www.nitesystem.com

Table of Contents

Need help?

Do you have a question about the NITE and is the answer not in the manual?

Page 1 This small plate will be used in step #13. Bergstrom, Inc. 2390 Blackhawk Road ● P.O. Box 6007 ● Rockford, IL 61125 ● ● 1-866-204-8570 www.nitesystem.com...
Page 2 Before You Start Remove Two Screws from the Back Panel Removal of these screws will provide the additional clearance needed to remove the blower. Flip Top Cover Up and Lean it Against the Back Leaving Wires Attached. Unplug the Blower Motor Power Wires...
Page 3 Before You Start Remove the 2 Screws from the Side Panel that Attach the Blower Mounting Plate Remove the 2 Phillips Head Screws from the Front Panel Under the Air Outlet Remove the Blower From the Unit...
Page 4 Before You Start The Mounting Plate Must be Removed and Turned Around Place the Blower Back Into the Unit With the Discharge Facing Up Reinstall Blower Support Bracket Screws Because the blower has been rotated, the screws removed in step #5 now need to be reinserted into the new holes indicated in the photo.
Page 5 Reconnect the Wires You Disconnected in Step #4 Reattach the Cover Put cover back on the NITE unit and reinsert and tighten all screws except for the 4 screws that attached the small cover plate. Also, since the blower has been rotated, the two...
