CNET CNSH-500 Product Specifications

TOTAL NETWORK SOLUTIONS
CNSH-500 is a super-compact plug & play switch with 5 dual speed N-Way ports. A built-in auto negotiation function
allows each port to automatically sense the widest possible bandwidth (10-200Mbps) and instantly set the port to
operate at that speed.
The CNSH-500 offers a user friendly design with all status LEDs conveniently located on the front panel and TP ports
placed along the back panel. To instantly add five (5) new bandwidths to, or to upgrade the performance of any
network, the palm-sized CNSH-500 is the perfect choice.

KEY FEATURES

Five (5) independent bandwidths with
10Mbps – 200Mbps capability.
Five (5) Switched ports with Auto-Negotiation
function.
128K bytes shared buffer memory.
1K MAC Address entries. (maximum)
Full wire speed "Store-and-Forward"
technology instantly eliminates bad packets.
Filtering/Forwarding rate: 148,800
packets/sec. per port max.
PRODUCT SPECIFICATIONS
Model
Standards
Ports
Media Support
Bandwidth
Forwarding/Filtering Rate
MAC Addresses
Buffer Memory
Duplex Modes
Auto-MDIX
LED Indicators
External Power Adapter
Power Consumption
Environment
Certifications
Dimensions
CNSH-500
Specifications are subject to change without notice
CNSH-500 F
100BASE-TX, IEEE 802.3u
10BASE-T, IEEE 802.3
Five (5) 100BASE-TX/10BASE-T
100BASE-TX Category 5 TP
10BASE-T Category 3, 4 or 5 TP
100BASE-TX/10BASE-T - 200/100/20/10Mbps, via Auto-Negotiation
148800 packets/second per port @ 100Mbps, maximum
14880 packets/second per port @ 10Mbps, maximum
1K MAC address entries (maximum)Self-learning
128K Bytes
All ports support Half-Duplex and Full-Duplex operation
All ports support Auto-MDIX which can detect and corrects crossover cables
One (1) for Power On / Off
One (1) per port for Link / Activity
Output 9VDC, 1Amp (according to country)
2.5W maximum
Operating Temperature: 0 ~ 45 C (32 ~ 113 F)
Storage Temperature: -20 ~ 70 C (-4 ~ 158 F)
Humidity: 10% ~ 90% Non-Condensing
FCC Class B and CE Mark approved
118 x 70 x 25 mm (4.64 x 2.75 x 0.98 inches)
November, 2003
10/100M
IVE PORT BPS
www.cnetusa.com
IEEE 802.3x Flow-Control support for Full-
Duplex operation.
Back-Pressure support for Half-Duplex
operation.
Palm sized with external power adapter.
IEEE 802.3u and 802.3 standards compliant.
Plug-&-Play with easy to read diagnostic
LEDs.
Five (5) ports Auto-MDIX detects and
corrects crossover cables.
CNSH-500 (H)
Trademarks & Trade Names belong to their owners
N-W S
AY WITCH
PS-0315-B1
