Rigol DS Series Firmware Upgrade Procedure

DS Series products Firmware Upgrade Procedure

Date: 11.26.2013

Solution:

System requirements:

IBM compatible PC

WINRAR software

An USB (flash) drive

If you choose to perform an upgrade and your unit is damaged, Rigol is not responsible

for the repair or shipping costs. The User assumes all responsibility.

Before the upgrade, please contact RIGOL Technical and Support Department to confirm

whether the current firmware version can be upgraded to the target version.

There is no firmware upgrade available if you current firmware version is below 02.04.

Doing an update despite you have a lower version will damage your Scope seriously.

Verify the USB (flash) drive that can be recognized by a Rigol oscilloscope (e.g. DS1102E) as

follows:

• When the oscilloscope is powered up, insert the USB drive (WITHOUT update file) into the

USB (Host) port which is located in the front of the oscilloscope.

• When it prompts "USB device install success", it indicates the flash drive is recognized by the

scope, as shown in Figure 1.

• Otherwise the USB drive is not compatible with the oscilloscope
