LED Indications
Red Light
Green Light
Orange Light
Please note that rotary encoder is in operation in parallel with PC commands. They both
work flawlessly and update the exact position of the motor.
Technical Specifications
Supply Voltage
Motor Compatibility
Motor Output
USB Connectivity
Thermal Sensor Resolution
Power Input Connector
Motor Connector
Dimensions
7
Pegasus Astro – Copyright 2016
Knob encoder set to 1/10 speed (5 steps)
Knob encoder set to normal (20 steps)
Knob encoder is disabled
9 - 15V DC (12V preferred)
DC motor - adjustable frequency PWM
Unipolar motors
Bipolar models
DC motor, max 0.8 Amp
Unipolar / Bipolar stepper motors, max 1.6 Amps (0.8 Amps
per phase)
USB 2.0 Type B plug
9-bit Celsius temperature measurements
2.1mm Centre Positive Socket
D Sub 9 female connector
115mm x 60mm x 30 mm
