Female D Sub
FOCUSER CONNECTION IN STEPPER MODE
PIN 1
PIN 2
PIN 3
PIN 4
PIN 5 - 9
FOCUSER CONNECTION IN DC MODE
PIN 1
PIN 2
PIN 3 - 9
4
Pegasus Astro – Copyright 2016
COIL 1+
COIL 1-
COIL 2+
COIL 2-
NO CONNECTION
POWER +
POWER -
NO CONNECTION
Stepper Motor
