DEMO MANUAL DC2570A
QUICK START PROCEDURE
V (20MHz BW) [50mV/DIV]
OUT
25A TO 37.5A LOAD STEP
100 s/DIV DC2570A F06
Figure 6. Output Voltage V vs Load Current (V = 1.0V)
OUT OUT
V (20MHz BW) [5mV/DIV]
OUT
2 s/DIV
DC2570A F07
Figure 7. Output Voltage Ripple at V = 12V, V = 1.0V, I = 50A
IN OUT OUT
Rev. 0
5
