100 AMP 120V ARC WELDER
ITEM: 55136
OWNER'S MANUAL AND SAFETY INSTRUCTIONS
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT'S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: (909) 628 4900 MON-FRI 9AM TO 3PM PST
Advertisement
Table of Contents
Related Manuals for Stark 55136
Summary of Contents for Stark 55136
- Page 1 100 AMP 120V ARC WELDER ITEM: 55136 OWNER’S MANUAL AND SAFETY INSTRUCTIONS SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY, OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION GENERAL SAFETY WARNINGS Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. SAFETY The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. - Page 3 IMPORTANT SAFETY INFORMATION Dress properly. DO NOT wear loose clothing, dangling objects, or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery, or long hair can be caught in moving parts. Air vents on the tool often cover moving parts and should be avoided. Wear the proper personal protective equipment when necessary.
- Page 4 IMPORTANT SAFETY INFORMATION Avoid overexposure to fumes and gases. Always keep your head out of the fumes. DO NOT breathe the fumes. Use enough ventilation or exhaust, or both, to keep fumes and gases from your breathing zone and general area. Where ventilation is questionable, have a qualified technician take an air sampling to determine the need for corrective measures.
- Page 5 MACHINE DESCRIPTION AND SPECIFICATIONS TEMPERATURE INDICATOR POWER SWITCH POWER CONTROL SCREW CURRENT SWITCH WORK PIECE TIE- TORCH TIE-IN FEATURES: ACCESSORIES: Rated input voltage: 110V Power supply cord No-load voltage: 48V Electrode holder with cord Current range: 40-100 amps Dia. of welding wire: Earth clamp 1.6 mm to 3.2 mm Brush...
-
Page 6: Operation
OPERATION CONNECTION OF THE WELDING END One end adjoins the cable for the welding torch through a quick joint and the other end adjoins the work piece by the cable with the quick joint. The quick joint at the output end must be screwed in a clockwise direction firmly. -
Page 7: Basic Welding Technique
OPERATION SETTING UP 1. Make practice welds on pieces of scrap the same thickness as your intended work piece to practice technique before welding anything of value. Clean the weld surfaces thoroughly with a wire brush or angle grinder; there must be no rust, paint, oil, or other materials on the weld surfaces, only bare metal. 2. -
Page 8: Strike Test
OPERATION CLEANING THE WELD 1. A weld from flux-core wire will be covered by slag. Use a Chipping Hammer to knock this off. Be careful not to damage the weld or base material. 2. Then, use a Wire Brush to further clean the weld or use an angle grinder (sold separately) to shape the weld. -
Page 9: Troubleshooting
TROUBLESHOOTING... -
Page 10: Please Read The Following Carefully
PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
