INSTALLATION INSTRUCTIONS
Co-Axial Flue Installations
Note: This appliance has been approved for co-axial flue application. If the flue (as
supplied by the manufacturer) is installed to an external wall or external fireplace.
(Refer installation diagram for Co-Axial Flue Installations Pages 10-11-12)
Single Flexi Installations
Note: This appliance has been approved for single flue pipe installation. If the unit and flue
pipe is installed in line with the manufacturer's installation instructions.
(Refer installation diagram for single flue pipe installations Pages 9-12-13-14-15)
CONFIGURATION 1
Single Flue Application:
CONFIGURATION 2
Co-Axial Flue Application: Insert Models for Installation on External Walls or External Fire

FLUEING REQUIREMENTS

Insert Models Pages (12-13-14-15-16) - Single Flexi Flue
Application.
SINGLE PIPE 40mm ø 5.1 METRES HIGH INCLUDING 2 X 45°
ELBOW, 1 X 90° ELBOW, 1m FLEXIBLE PVC SECTION AND
ONE 75mm COWL.
places Pages 10-11-12
CO-AXIAL FLUE INTERNAL PIPE 40MM ø EXTERNAL PIPE
65MM ø BOTH PIPES IN PVC UP TO 1 METRE LENGTH FOR
WALL PENETRATION.
8
