Bunn AXIOM 35-3 Installation & Operating Manual

Bunn AXIOM 35-3 Installation & Operating Manual

Bunn axiom 35-3: user guide

Advertisement

INSTALLATION & OPERATING GUIDE
BUNN-O-MATIC CORPORATION
POST OFFICE BOX 3227
SPRINGFIELD, ILLINOIS 62708-3227
PHONE: (217) 529-6601
FAX: (217) 529-6644
To ensure you have the latest revision of the Operating Manual, or to view the Illustrated Parts
Catalog, Programming Manual, or Service Manual, please visit the Bunn-O-Matic website, at
www.bunn.com. This is absolutely FREE, and the quickest way to obtain the latest catalog and
manual updates. For Technical Service, contact Bunn-O-Matic Corporation at 1-800-286-6070.
39130.0000G 12/09 ©2008 Bunn-O-Matic Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AXIOM 35-3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bunn AXIOM 35-3

  • Page 1 To ensure you have the latest revision of the Operating Manual, or to view the Illustrated Parts Catalog, Programming Manual, or Service Manual, please visit the Bunn-O-Matic website, at www.bunn.com. This is absolutely FREE, and the quickest way to obtain the latest catalog and manual updates. For Technical Service, contact Bunn-O-Matic Corporation at 1-800-286-6070.
  • Page 2: Warranty

    SOLE OPTION AS SPECIFIED HEREIN, TO REPAIR, REPLACEMENT OR REFUND. In no event shall BUNN be liable for any other damage or loss, including, but not limited to, lost profits, lost sales, loss of use of equipment, claims of Buyer’s customers, cost of capital, cost of down time, cost of substitute equipment, facilities or services, or any other special, incidental or consequential damages.
  • Page 3: Table Of Contents

    WA R M E R S A N D S U R FAC E S A R E H OT #02765.0000 INTRODUCTION ⁄ gallon batch of coffee into an awaiting server. The brewer may have USER NOTICES PN: 00658.0000G 02/08 © 1985 BUNN-O-MATIC CORPORATION #00658.0000 WARNING • DO NOT OVERLOAD CIRCUIT. • ALWAYS ELECTRICALLY GROUND THE CHASSIS.
  • Page 4: Electrical Requirements

    The brewer must be disconnected from the power source until specified in Initial Set-Up. Refer to Data Plate on the Brewer, and local/national electrical codes to determine circuit requirements. ELECTRICAL HOOK-UP (All Models) CAUTION – Improper electrical installation will damage electronic components. An electrician must provide electrical service.
  • Page 5: Single/Dual Volt Models

    Requirements for brewers with an attached cord set are as follows: Note: This electrical service re- quires 2 current carrying conduc- tors (Neutral, and L1) and a separate conductor for earth ground. POWER CORD NEUTRAL WHITE WHITE NEUTRAL L1 BLACK L1 BLACK GREEN 120V 2 WIRE + GROUND...
  • Page 6: Plumbing Requirements & Initial Set-Up

    25 feet from the facilitate moving the brewer to clean the counter top. Bunn-O-Matic does not recommend the use of a saddle valve to install the brewer. The size and shape of the hole made in the supply line by this type of device may restrict water flow.
  • Page 7: Operating Controls & Coffee Brewing

    COFFEE BREWING 1. Begin each brew cycle with a clean empty brew funnel. 2. Insert a BUNN filter into the funnel. 3. Pour (or grind) fresh coffee into the filter and level the bed of grounds by gently shaking. 4. Slide the funnel into the funnel rails until it stops.
  • Page 8: Cleaning & Tank Drain

    1. The use of a damp cloth rinsed in any mild, nonabrasive, liquid detergent is recommended for cleaning all surfaces on Bunn-O-Matic equipment. 2. Check and clean the sprayhead. The sprayhead holes must always remain open. Insert the short end of the sprayhead cleaning tool into each of the five water outlets of the plastic sprayhead to remove any mineral deposits (Refer to Fig 1) 3.
  • Page 9: Programming Switches

    ADJUSTMENTS & OPTIONAL SETTINGS BUNN ® Using the menu-driven display on the front of the brewer, the operator has the ability to alter or modify various brewing parameters such as brew lockout, brew volume, brew strength, etc. This allows for the precise brewing of various flavors of coffee.
  • Page 10 ADJUSTMENTS & OPTIONAL SETTINGS (CONT.) PROGRAMMING FUNCTIONS - FLOW CHART BREW LOCKOUT ? DONE ENABLE ADS ? DONE ENTER PASSWORD UNITS METRIC DONE ENG BrewWIZARD BREW OZ: 64.0 DONE ENTER SERVICE #? LEVEL 2 SET PASSWORD SET TEMP: 200° DONE (CONT.) Page 10 BREW METER...
  • Page 11 ADJUSTMENTS & OPTIONAL SETTINGS (CONT.) LEVEL 2 (CONT.) ENTER ASSET # ? ENABLE CLEAN DONE ENABL WARMER OFF DONE (These two screens will change if "BrewLogic" is enabled) SPRAY OZ/M: 25.0 DONE SERVICE TOOLS ? SET PULSE BREW ? Enabl EnergySavr DONE YES REFILL DONE...
