- Page 1 Yorkville OWNER'S MANUAL MANUEL DE'UTILISATEUR ES Series Powered Subwoofers ES12P • ES15P • ES18P • ES21P...
-
Page 2: Important Safety Instructions
IM PORTA N T S A FE TY I N S TRUC TI ON S This lightning flash with arrowhead symbol, within The exclamation point within an equilatereal triangle is intended to alert the an equilateral triangle, is intended to alert the user to the presence of user to the presence of important operating and maintenance (servicing) uninsulated “dangerous voltage”... -
Page 3: Input Mode Switch
When used in a setup where only one signal is provided to a speaker, such as a mono system or stereo with more than one ES Series Powered Subwoofer, you can use any of the Link jacks. - Page 4 AND IS NOT FOR STREAMING AUDIO! 2. Sub Level Control The Sub Level control adjusts the amount of bass added to the sound system by the ES Series Powered Subwoofer. This adjusts for the relative sensitivity of the companion full-range speak- ers and the desired system frequency response.
-
Page 5: Bluetooth Control
The ES Series Powered Subwoofers have a DSP-based circuit to prevent clipping, over power and over excursion. At high levels the limiter will limit the gain of the ES Series Powered Sub- woofer and hence if the user attempts to set the subwoofer level control at a high level, the resulting setting will be overridden by the internal protection. - Page 6 Caisson de Basse Actifs Série ES à Pavillon Avec Mo- teur Monté à l’Arrière Les caissons de basse de la série ES sont des caissons de basse de qualité supérieure avec des amplificateurs de puissance intégrés. Conçus comme un ajout facile à installer sur n’importe quel système de sonorisation, les caissons de basse amplifiés de la série ES rehaussent les graves d’un système sonore typique avec le moins de complications possibles.
- Page 7 MONO BLEND INPUT LINE Line Level Sources Only! NOTE: THE YORKVILLE APP IS NEEDED TO CONTROL FUNCTIONS THROUGH BLUETOOTH AND IS NOT FOR STREAMING AUDIO! AVERTISSEMENT: Ne branchez pas deux sources de niveau haut parleur à un seul caisson de basse actif de série ES! Augmenter la commande de niveau en mode de limitation n’augmentera...
- Page 8 Cette commande active ou désactive la connexion Bluetooth ™ avec une tablette ou un téléphone intelligent en utilisant l’application Yorkville. Appuyez sur le bouton Bluetooth ™ pendant plus de 4 secondes pour réinitialiser le caisson de basse actif de la série ES aux réglages d’usine.
- Page 9 9. Adaptateur de Montage de Tube de Support Les caissons de basse amplifiés de la série ES sont équipés d’un adaptateur de montage de pied intégré qui peut être utilisé avec l’accessoire Yorkville SW-Teletube pour supporter les enceintes pleine bande amplifiée élite.
- Page 10 STEREO ACTIVE SPEAKER CONFIGURATION INPUT Switch set to LINE ES__P MIXER STEREO PASSIVE SPEAKER CONFIGURATION INPUT Switch set to SPKR ES__P #1 ES__P #2 PWR AMP STEREO ACTIVE SPEAKER CONFIGURATION INPUT Switch set to LINE ES__P #1 ES__P #2 MIXER...
- Page 11 CONFIGURATION AVEC HAUT-PARLEUR ACTIF STÉRÉO Commutateur d'ENTRÉE réglé à la position "LINE" ES__P MIXER CONFIGURATION AVEC HAUT-PARLEUR PASSIF STÉRÉO Commutateur d'ENTRÉE réglé à la position "SPKR" ES__P #1 ES__P #2 PWR AMP CONFIGURATION AVEC HAUT-PARLEUR ACTIF STÉRÉO Commutateur d'ENTRÉE réglé à la position "LINE" ES__P #1 ES__P #2 MIXER...
- Page 12 Specifications ES12P ES15P ES18P ES21P System Type Rear Horn Loaded Subwoofer Rear Horn Loaded Subwoofer Rear Horn Loaded Subwoofer Rear Horn Loaded Subwoofer Active or Passive Active Active Active Active Program Power (watts) 1200 watts (1600 watts Peak) 1800 watts (3600 watts Peak) 1600 watts (3200 watts Peak) 2400 watts (3600 watts Peak) Max SPL (dB)
- Page 13 B l o c k D i a g r a m f o r E S S e r i e s P owe r e d S u b wo o f e r s D E S I G N E D &...
- Page 14 This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 15 Unlimited Warranty Yorkville's two and ten-year unlimited warranty on this product is transferable and does not require registration with Yorkville Sound or your dealer. If this product should fail for any reason within two years of the original purchase date (ten years for the wooden enclosure), simply return it to your Yorkville dealer with original proof of purchase and it will be repaired free of charge.
- Page 16 WORLD HEADQUARTERS CANADA U.S.A. Yorkville Sound Limited Yorkville Sound Inc. 550 Granite Court 4625 Witmer Industrial Estate Pickering, Ontario Niagara Falls, New York L1W 3Y8 CANADA 14305, USA Voice: 905-837-8481 Voice: 716-297-2920 Fax: 905-837-8746 Fax: 716-297-3689 Manual-Owners-ES_P-00-2v4 • January 10, 2021...
