This lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. Ce symbole d’éclair avec tête de flèche dans un triangle équilatéral est prévu pour alerter l’utilisateur de la présence d’un «...
For normal operation connect the LS700P "INPUT LEVEL" switch should be set to "SPEAKER ." If the audio source does not have a "U" ground, eg. a ground pin on the AC cord, the "INPUT GROUND" switch must be set to "GROUNDED." The the full range speakers.
Page 4
+4 dBV. This also is the setting to give a sensitivity of 2.83 Vrms (1 watt 8-Ohms) for 100 dB spl when set for speaker level input. With a typical full range companion speaker this will give flat response. In either line or speaker...
Page 5
This can happen without audible distortion since the filters will filter out the distortion. LS700P Configuration Examples LS700P POWER FULL–RANGE SUBWOOFER AMPLIFIER SPEAKER/s Output ONE SUBWOOFER, WITH MONO SYSTEM LS700P POWER FULL–RANGE SUBWOOFER AMPLIFIER...
LF Power Amplifier (Watts) Passive Convection Cooling Scheme Power Cable Power Switch Power Consumption (typ/max) 300/480VA (4A@60hz, 2A@50hz) 2 line/speaker level inputs, 2 link (in/out) Inputs - 1/4" Jacks Level Controls Main Volume EQ Controls High Frequency Cut-Off Other Controls / Features...
Page 7
Pour opération normale, branchez simplement le gamme. Réglez le commutateur "INPUT LEVEL" à la position "SPEAKER." Le commutateur "INPUT GROUND" doit être réglé à la position "GROUNDED" si l'appareil de source sonore n'est pas munis d'un cordon d'alimentation avec lame LS700P de mise à...
Page 8
2.83Vrms (1 watt 8-Ohms) pour une pression sonore de 100dB quand le sélecteur d’entrée est réglé à la position “speaker level.” Dans un ensemble typique avec haut-parleur pleine bande, ce réglage offrira une courbe de réponse en fréquence uniforme.
Page 9
signal acheminé aux haut-parleurs pleine gamme. Le LS700P ne prélèvera pas de puissance de l'amplificateur qui propulse les haut-parleurs pleine gamme. Veuillez noter qu'un filtre séparateur externe n'est pas nécessaire. En plus d'accommoder le cabinet pleine gamme, le jack PARALLEL THRU permet l'utilisation de plusieurs LS700P branchés en parallèle.
Page 10
Yorkville LS700P SPECIFICATIONS Type de système Subwoofer Active or Passive Active Puissance Nominale (Watts) Niveau de Pression Sonore Max (dB) Réponse en Fréquence (Hz +/- 3db) 45 - 125 2 x 10 pouces Configuration des HP Driver(s) pour graves 2 x 10 pouces, boitier en métal coulé Puissance Nominale fréquences Graves (Watts) 2 x 350 Limite Électronique (thermal, excursion, écrêtage)
Page 11
Two & Ten Year Warranty & Unlimited Warranty Yorkville's two and ten-year unlimited warranty on this product is transferable and does not require registration with Yorkville Sound or your dealer. If this product should fail for any reason within two years of the original purchase date (ten years for the wooden enclosure), simply return it to your Yorkville dealer with original proof of purchase and it will be repaired free of charge.
Page 12
WORLD HEADQUARTERS CANADA U.S.A. Yorkville Sound Yorkville Sound Inc. 550 Granite Court 4625 Witmer Industrial Estate Pickering, Ontario Niagara Falls, New York L1W-3Y8 CANADA 14305 USA Voice: (905) 837-8481 Voice: (716) 297-2920 Fax: (905) 837-8746 Fax: (716) 297-3689...
