  • Page 1 BRAIN 15...
  • Page 2 24. Eloigner de la portée des enfants les radiocommandes ou tout autre générateur d’impul- 5. GENIUS declines all liability caused by improper use or use other than that for which the sions, pour éviter tout actionnement involontaire de l’automatisme.
  • Page 3 9. GENIUS is niet aansprakelijk als de regels der goede techniek niet in acht genomen zijn bij de bouw van het sluitwerk dat gemotoriseerd moet worden, noch voor vervormingen HINWEISE FÜR DEN INSTALLATIONSTECHNIKER...

  • Page 4: Eu Declaration Of Conformity

    BRAIN 15 Page 13 Guide for the installer INDEX 1. WARNINGS page.13 2. LAYOUT AND CONNECTIONS page.13 3. TECHNICAL SPECIFICATIONS page.14 3.1. Description of components page.14 3.2. Description of terminal-boards page.14 3.3. Anti-crushing function page.14 3.4. Over pushing stroke page.14 4.

  • Page 5: Layout And Connections

    Always separate power cables from control and safety cables (push-button, receiver, photocells, etc.). To avoid any electrical disturbance, use separate sheaths or a screened cable (with the screen earthed). 2. LAYOUT AND CONNECTIONS MOTOR CABLES AT LEAST 2.5 mm Fig. 1 The power supply is related to the BRAIN 15 purchased version.

  • Page 6: Technical Specifications

    Vac and 26 Vac. Voltage must be measured load free. current consumption or the encoder of the motors connected to the BRAIN 15 equipment. 3.1. Description of components If the gate detects an obstacle during the opening or closing move-...

  • Page 7: Automatic Setup

    Before performing the Setup, select the operator con- point is reached. nected to the BRAIN 15 equipment with the DS3 and When at rest, leaf 2 starts the pause time count. At the end DS4 dip-switches.
  • Page 8 BRAIN 15 Page 17 Guide for the installer 13. Send an OPEN command to determine the start of the Tab. 4 - Programming features decelerated part and wait until the closing mechanical stop point is reached. 14. When leaf 1 reaches the closing mechanical stop point, the setup phase is completed.

  • Page 9: Installation Of Bus Accessories

    Page 18 BRAIN 15 Guide for the installer 7.INSTALLATION OF BUS ACCESSORIES Tab. 5 - Addressing of BUS Photocells This board is supplied with a BUS circuit enabling easy connection Dip1 Rif. Tipologia of a high number of BUS accessories (e.g. up to 16 photocells pairs), appropriately programmed, using only two cable without polarity.

  • Page 10: Memory Storing The Radio Code

    BRAIN 15 Page 19 Guide for the installer Give an OPEN impulse, leaves will move and the BUS 8. MEMORY STORING THE RADIO CODE learning procedure is over. The control board has an integrated 2-channel decoding system. The board has memory stored the BUS accessories. Follow the...

  • Page 11: Automated System Test

    Page 20 BRAIN 15 Guide for the installer storage executed. • Quickly press twice the push-button of the memory stored radio control. The automated system performs one opening operation. Make sure that the automated system is free of any obstacle created by persons or things.

  • Page 12: Function Logics

    BRAIN 15 Page 21 Guide for the installer 11. FUNCTION LOGICS Tab. 7 LOGIC “A” PULSES AUTOMATED SY- OPEN A OPEN B STOP FSW OP FSW CL FSW CL/OP STEM STATUS opens released opens and closes no effect (OPEN no effect (OPEN...
  • Page 13 Page 22 BRAIN 15 Guide for the installer Tab. 10 LOGIC “EP” PULSES AUTOMATED SY- OPEN A OPEN B STOP FSW OP FSW CL FSW CL/OP STEM STATUS opens released no effect (OPEN no effect (OPEN no effect (OPEN CLOSED...
  • Page 14 BRAIN 15 Page 23 Guide for the installer no effect (OPEN no effect (OPEN no effect (OPEN CLOSED opens the leaves no effect no effect disabled) disabled) disabled) OPENING no effect closes leaves stops operation locks operation no effect locks operation...
  • Page 15 Pagina 68 BRAIN 15 NOTE - NOTES - NOTE - NOTAS - ANMERKUNG - OPMERKINGEN...
  • Page 16 Sede legale: FAAC S.p.A. Soc. Unipersonale Via Calari, 10 - 40069 Zola Predosa BOLOGNA - ITALY Tel. +39 051 61724 - Fax +39 051 758518 www.geniusg.com BRAIN 15 00058I0821 - Rev.4...
