CE Kit
Dingo 320-D Compact Utility Loaders with 220000001 and
Higher Serial Numbers
Model No. 22360
Loose Parts
Note: Use the chart below to identify parts for assembly.
Description
Brake bracket
Brake bar
Brake bar bracket
Flange-head bolt
Parking brake cable
Convoluted cable tube
Locking collar with set screw
Large spring
Bolt, 5/16 x 1 in.
Locknut, 5/16 in.
Parking brake lever assembly
Clevis pin, 3/4 in.
Cotter pin, 3/4 in.
Wheel hub assembly
Cotter pin, 1-1/2 in.
Loader valve lock assembly
Self-tapping screw, 1/4 x 5/8 in.
Auxiliary hydraulics lever gate
Spacer
Lever mount block
Thick washer
Lock washer, 5/16 in
Flange-head bolt, 8 x 20 mm
Auxiliary hydraulics lever
Carriage bolt, 1/4 x 2 in.
Locknut, 1/4 in.
Torsion spring
Self-tapping screw, 1/4 x 1-3/8 in.
Lock washer, 1/4 in.
Nut, 1/4 in.
Self-tapping screw, 5/16 x 3/4 in.
2002 by The Toro Company
8111 Lyndale Avenue South
Bloomington, MN 55420-1196
Qty.
2
2
2
2
1
1
2
1
Installing the parking brake
4
4
1
1
1
2
2
1
Installing the loader valve lock
2
1
2
1
1
1
1
Installing the auxiliary hydraulics lever gate
1
2
2
1
1
1
1
1
Securing the rear access panel
1
Form No. 3328-524
Installation Instructions
Use
All Rights Reserved
Printed in the USA
Advertisement
Related Manuals for Toro CE Kit
Summary of Contents for Toro CE Kit
- Page 1 Self-tapping screw, 1/4 x 1-3/8 in. Lock washer, 1/4 in. Nut, 1/4 in. Self-tapping screw, 5/16 x 3/4 in. Securing the rear access panel 2002 by The Toro Company 8111 Lyndale Avenue South All Rights Reserved Bloomington, MN 55420-1196 Printed in the USA...
-
Page 2: Preparing The Traction Unit
Description Qty. CE information decal, 105-8424 European Noise decal, 105–8405 Danger decal, 100-1701 Caution decal, 100-1702 Speed limiter decal, 100-1703 Installing the CE decals Control panel decal, 100-1706 Pinch decal, 100-8821 No rider decal, 100-8822 Hydraulic oil decal, 93-6686 Radiator cap decal, 93-7840 Operator’s Manual Replace the Operator’s Manual and supplement the Parts Catalog. - Page 3 3. Insert the cable through the right brake bracket as 7. Set the cable into the left brake bar bracket, and secure shown in Figure 3. it firmly in place with a locking collar and set screw assembly (Fig. 7). The cable must be securely held in 4.
-
Page 4: Installing The Parking Brake Lever
3. Position the brake assembly under the traction unit 2. Secure the cable to the lever with a clevis pin and cotter against the back wall of the frame with the brake bars pin (3/4 in.) (Fig. 11). through the rectangular holes in the sides of the frame (Fig. -
Page 5: Installing The Rear Wheel Hubs
Figure 13 Figure 15 1. Air cleaner bolts and nuts 2. Air cleaner 1. Rear drive shaft (left side) 5. Slide the slots in the lever plate over the air cleaner 2. Disengage the parking brake lever. bolts, between the frame and the air cleaner mounting bracket (Fig. - Page 6 Adjusting the Parking Brake 1. Push the parking brake lever all the way up and forward to disengage it. 2. Check the brake bars protruding from either side of the traction unit. The bars should be about 1/8 in. (0.3 cm) from the wheel hub and neither bar should be able to move side to side.
- Page 7 2. Remove the 2 bolts, locknuts, and spacers securing the 9. Install the lever spring between the lever and the gate auxiliary hydraulics valve to the frame (Fig. 20). (Fig. 20). Discard the spacers. 10. Install the self-tapping screw (1/4 x 1-3/8) into the hole on top of the gate (Fig.
- Page 8 Installing the Decals Install the decals in the positions indicated in the following table. Place each decal directly over the US English decal that corresponds to the CE decal you are installing. Note: Decals 105-8424, 105-8405, and 100-8822 do not have an US English equivalent installed on the traction unit. 1.
- Page 9 Location US English 4 locations on the loader arms 100-6141 100-8821 2 locations on the loader arm crossbar: one facing the operator and one facing forward 100-8822 On the radiator 106-5976 99-3157 (US English) On the control On the control panel 100-1706 (CE)
- Page 10 Location US English On the left side of the frame under the fuel tank 105-8424 On the left side of the frame under the fuel tank 105-8405...
