Digitrax PR3 XtRa Quick Start Manual

PR3 XtRa
PR3 Xtra Features
Multifunction USB 2.0 PC connectivity for your railroad
Digitrax SoundLoa der
SFX decoders
Programs CVs for most DCC decoders
LocoNet MS100 mode with Fully Buffered Input and Output data
Runs on Windows XP, Vista, 2000, 7, 8, 8.1 and 10
Runs on Mac OS with JMRI
No external power needed for MS100 mode
For Stand Alone Programming Mode the included external power supply
is required
Automatic configuration. No jumpers or switches required. Configurations
can be set by software or manually
Selectable LocoNet termination. For standalone operation without a
Command Station
LED status indicator lights
Small, convenient package
Firmware updates available from Digitrax Web site
Meets FCC Class B requirements
Parts List
1 PR3 Xtra Programmer
1 PS14 Power Supply
Using Digitrax SoundLoader
Xtra Programmer you can create, manage, test, and download Digitrax sound
projects (.spj) in your SoundFX decoders. You can select which sound files
(.wav) you want to have associated with different sound sequences in any
sound project and download the modified sound project to any Digitrax
SoundFX decoder. This gives you the ability to customize your sound
decoders any way you like!
©2013 Digitrax, Inc.
Complete Train Control
Run Your Trains, Not Your Track!
PR3 Xtra Decoder Programmer
compatible. Programs Digitrax sound projects in to
TM
software with your PC and the Digitrax PR3
TM
www.digitrax.com
USB Programmer/Interface
1 USB Cable
1 Instruction Sheet
