Whittier Wood 3527DUET Assembly Instruction Manual

Addison 38"w vinyl record station

Advertisement

Quick Links

Model #
3527DUET
Addison 38"W
Vinyl Record
Station
DUET finish
Thank you for allowing us to help you furnish your
home. We are certain you will be delighted with
your new furniture for many years to come.
If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a
replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you
cannot order replacement parts through your dealer, please contact our customer service department.
Customer Service: 800-653-3336 • Outside the U.S.: 541-687-0213
CUSTOMER SERVICE
Hours: Our friendly customer service staff can be reached:
Monday-Friday 8:00 a.m. to 5:00 p.m. (Pacific Time).
You may leave a message 24 hours a day, seven days a week.
Fax: 541-687-2060• Email: info@whittierwood.com
P.O. Box 2827
Eugene, OR 97402 USA

IMPORTANT NOTES:

• Wood can be susceptible to changing color over time when exposed to
strong sunlight. Use window shades, drapes or blinds to protect your
furniture. To help the surface age evenly and avoid dark and light
spots, periodically move items to expose the entire surface to an even
amount of light so it may develop a uniform patina.
• For normal household use only. Not recommended for commercial use.
• Do not climb, sit or stand on this piece of furniture.
• Do not overload the drawers or shelves.
• Unload items before you move this unit.
• Before you begin your project, completely read the Assembly
Instructions.
• This assembly requires two people.
Children have died from furniture tipover. To reduce the risk of
furniture tipover:
ALWAYS install tipover restraint provided.
NEVER allow children to stand, climb or hang on drawers,
doors or shelves.
NEVER open more than one drawer at a time.
Place heaviest items in the lowest drawers.
Refer to TV manufacturers User Guide for additional instructions to
secure television.
Use of tipover restraints may only reduce, but not eliminate,
the risk of tip over.
Attention: Attached to the bottom of or included with this unit is a tipping
restraint kit. When you receive your furniture, be sure to find and install
the tipping restraint as instructed in the kit. If you cannot locate the
restraint, please contact us immediately for replacement.
Drilling, sawing, sanding or machining wood products can expose you to
wood dust, a substance known to the state of California to cause cancer.
Avoid inhaling wood dust or use a dust mask or other safeguards for
personal protection.
For more information go to: www.p65warnings.ca.gov/wood
This product can expose you to chemicals, including formaldehyde,
which are known to the State of California to cause cancer.
For more information go to: www.p65warnings.ca.gov/furniture
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
Production Code:
VN

WARNING

08/19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3527DUET and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Whittier Wood 3527DUET

  • Page 1 If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you cannot order replacement parts through your dealer, please contact our customer service department.
  • Page 2 3527DUET Addison 38"W Vinyl Record Station Parts List Please identify the parts and check that quantities received match those on this list. If you need to replace a part, refer to the following letter and part name. Part Description Quantity...
  • Page 3 3527DUET Addison 38"W Vinyl Record Station Parts List Part Description Quantity Hinge Plate (attached) 1/4" x 20mm Insert Nut (inserted) 5/32" x 10mm Insert Nut (inserted) Black Walnut Pull (attached) Hex Bumper (attached) Front 4-Hole Bracket (attached) Back 6-Hole Bracket (attached)
  • Page 4 3527DUET Addison 38"W Vinyl Record Station Assembly Instructions Tools Required: Phillips Screwdriver, Pencil. Remove screws from the plywood supports and side aprons. Recycle or discard. See Figure 1. Plywood Supports Fig. 1 Place the chest at its final destination. Rotate the Small Adjustable Glides (Y) on the bottoms of the legs until the unit is level.
  • Page 5 3527DUET Addison 38"W Vinyl Record Station Assembly Instructions To move the Adjustable Shelf (C), remove the #6 x 1/2" Undercut Screws (H) and the Shelf (C). Reposition the Shelf Brackets (ZA) to the desired positions, replace the shelf and insert the screws.
  • Page 6 3527DUET Addison 38"W Vinyl Record Station Assembly Instructions The Tray Bottom Assembly (F) is a removable insert for the Tray Assembly (E). See Figure 5. It serves two purposes; the lip at the back keeps the records at an angle and in case the Tray Assembly is damaged, it can be removed as shown by the arrows in Figure 5 to reveal the screws that attach the Tray Assembly (E) to the case.
  • Page 7 Before you begin this assembly, identify each part and make sure the quantities received match what is on this list. If you need to replace a part, contact Whittier Wood Furniture customer service and refer to the following list for its name and letter code.
  • Page 8 3527DUET Addison 38"W Vinyl Record Station Assembly Instructions Move the item back into position against the wall and reach underneath the piece of furniture to grasp the loop in the free end of the strap. Pull the free end of the strap until portion between the Cam Buckle (A) and the back apron of the item is tight.
