Model #
3506AFGACa; 3506AFCAFa
McKenzie Console Desk
AFGAC = Glazed Antique Cherry finish
AFCAF = Caffè finish
Congratulations!
This fine piece of furniture will make a gorgeous addition to
your home. For the best results, read the Assembly
Instructions before you begin your project.
Service Policy: We will replace any part that is defective,
missing or damaged during assembly. For a replacement
part, directly contact Whittier Wood Products customer
service department by phone, fax, mail or email.
Hours: Our friendly customer service staff can be reached
Monday-Friday 7:00 a.m. to 5:00 p.m. (Pacific Time). You
may leave a message 24 hours a day, seven days a week.
800-653-3336 • Outside the U.S. or Canada: 541-687-0213 • Fax: 541-687-2060
CALL US FIRST! Do not return this item to the store
www.whittierwood.com • P.O. Box 2827 • Eugene, Oregon 97402, U.S.A.
P.O. Box 2827
Eugene, OR 97402 USA
IMPORTANT NOTES:
For normal household use only. Not recommended for
commercial use.
Do not climb, sit or stand on this piece of furniture.
Do not overload the drawers.
Unload items before you move this unit.
Before you load or move this unit, tighten all screws and
supports.
Before you begin your project, completely read the
Assembly Instructions.
Store this item: 1- in its box; 2- in a dry place; 3- in
temperatures that range from 40°F to 90°F (not on a cold
and possibly damp cement floor).
Periodically inspect your furniture for any loose glue
joints, screws or any other problem that might affect the
stability of your furniture. Tighten or repair as needed.
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
To Order: Provide the finish and furniture model number
(upper portion of this page), the part letter, production
code, quantity needed, reason for replacement and your
full name, address and telephone number.
Parts ship from our Eugene, Oregon factory within one or
two business days from the time we receive your request.
Please allow five to ten business days for delivery.
Production Code:
VN
05/13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3506AFGACa and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Whittier Wood 3506AFGACa

Summary of Contents for Whittier Wood 3506AFGACa

  • Page 1 For a replacement (upper portion of this page), the part letter, production part, directly contact Whittier Wood Products customer code, quantity needed, reason for replacement and your service department by phone, fax, mail or email.
  • Page 2 3506AFGACa; 3506AFCAFa McKenzie Console Desk Parts List Please identify the parts and check that quantities received match those on this list. If you need to replace a part, refer to the following letter and part name. Part Description Quantity Lift Top Assembly (attached)
  • Page 3 3506AFGACa; 3506AFCAFa McKenzie Console Desk Parts List Part Description Quantity #8 x 1-1/4" Black Screw (inserted) 1/4" x 20mm Insert Nut (inserted) Small Adjustable Glide (installed) 1/4" x 13.5mm Insert Nut (inserted) 1/4" x 40mm Bolt Wood Dowel (inserted) Velvet Pad (attached)
  • Page 4 3506AFGACa; 3506AFCAFa McKenzie Console Desk Assembly Instructions Tools Required: Hex Wrench (provided); Phillips Screwdriver, Mallet or Padded Hammer. Remove the Hutch Drawers (H) from the Case Assembly (C). Turn the Case Assembly (C) upside-down on a clean protected surface. Using the Hex Wrench (ZH) attach the Left Side Assembly (D) to the case assembly with two 1/4"...
  • Page 5 3506AFGACa; 3506AFCAFa McKenzie Console Desk Assembly Instructions Using the pocket drilled hole as a guide, secure the front legs of the Left Side Assembly and the Right Side Assembly to the case assembly with two #8 x 1-1/4" Pan Head Screw (Y).
  • Page 6 3506AFGACa; 3506AFCAFa McKenzie Console Desk Assembly Instructions Using the pilot holes, secure Back Panel to back legs of the Left Side Assembly and the Right Side Assembly with six #6x5/8" Philtruss Screws (W). See Figure 5. Fig. 5 Insert the Hutch Drawers (H). Place the console at its final destination. Rotate the Adjustable Glides (ZC) found at the bottom of each leg until the unit is level.
