PARTS LIST Key Qty Description Qty Description OUTER TOP LID COOKING GRATE, MAIN INNER LINER, F/ LID WARMING RACK HANDLE, F/ TOP LID SIDEBURNER END CAPS, F/ HANDLE ELECTRODE, F/ SIDEBURNER LOGO PLATE, W/ TEMP GAUGE SIDEBURNER GRATE HARDWARE F/ TOP LID CASTER, LOCKING RUBBER BUMPER, RECTANGLE CASTER, FIXED...
Page 13
ASSEMBLY Place bottom shelf upside down. Insert Bent U Pin into the caster mounting plate to lock it in place, shown A. Spin the caster clockwise into the threads on the bottom shelf until secure. Remove the Bent U Pin and repeat for remaining casters.
Page 14
Place lower back panel between side panels at rear of bottom shelf. Secure lower back panel to side panels using two 1/4-20x1/2” screws on each side. 1/4-20x1/2” screw Lower back panel This step requires two people to lift and position grill head onto cart.
Page 15
Insert front brace under control panel and between cart side panels. Make sure door hinge pins are on the top side and facing the front. 1/4-20x1½” fiber Secure upper holes using one screw and washer on each side. 1/4-20x1½” Secure lower holes using one screw on each side.
Page 16
#10-24x3/8” screws, Attach right side fascia to right side shelf using four lock washers and flat washers, shown Insert flange on right side shelf into side shelf brackets on right side of firebox, shown 1/4-20x3/4” 1/4” Attach right side shelf using two screws and nut, shown #8x3/8”...
Page 17
#10-24x3/8” Attach left side fascia to left side shelf using four screws, lock washers and flat washers, shown Insert flange on left side shelf into side shelf brackets on side of firebox, shown 1/4-20x3/4” 1/4” Attach left side shelf using two screws and nuts, shown #8x3/8”...
Page 18
First, remove the two screws and lock washers attached to the sideburner valve bracket. Position sideburner valve bracket beneath sideburner shelf fascia so that valve stem comes through larger center hole in fascia. Align the holes on valve bracket with left and right holes on fascia. Secure using screws and lock washers that were removed from bracket, shown Place sideburner bezel over valve stem on front side of fascia.
Page 19
Insert sideburner into left shelf. The stud on bottom of the burner fits into the rear small hole in sideburner drip pan, shown A . Secure burner to sideburner drip pan with Wing nut, shown B. Under sideburner shelf, attach sideburner ignitor wire to electrode. Make sure burner tube engages sideburner valve, shown B . Place sideburner cooking grate onto sideburner shelf, aligning grate legs with holes in shelf, shown C .
Page 20
Connect each of the wires from the main burner electrodes, and sideburner electrode into the back of the Electronic Ignition Module. otal (4) connections. Connect the two wires[(a) and (b)] from the switch wiring harness into the back of the Electronic Ignition Module. Total (2) connections, shown Release the cap and nut from electronic ignition module.
Page 21
Insert the pin on bottom of doors into hole in bottom shelf. Press upper hinge pin in front brace, align hinge hole on top of door, and release hinge pin into door. PRESS Top of door Right door on bottom of door Left door Place trough into fire box.
Page 22
Place cooking grates onto the firebox as shown. Warming Rack Warming Rack Place the onto the the firebox. Make sure insert the ends into the holes properly as shown. Warming Rack Cooking rate Fill and leak check the tank before attaching to grill and regulator (see Use & Care section). LP TANK IS SOLD SEPARATELY.
