5 Parts overview Base station

A
1
2
3
Illustration 1: All parts of the base station
1 Housing
3 Indoor sensor
5 DOWN/RAIN HISTORY button (decrease
value or show 30 days precipitation his-
tory)
7 RAIN SINCE/CLEAR button (show precip-
itation since last reset or delete stored
precipitation values)
9 WEATHER/ABS/REL button (set weather
or change barometric pressure type)
11 Stand, fold-out
Battery compartment cover
15 OUT-TEMP ALERT button (set and en-
able outdoor temperature alert)
4
5 6 7
8
9
10
11 12
2 Display
4 MODE/SET button (change display mode
or settings)
6 UP/RCC/ALARM button (increase value or
enable alarm)
8 Wall mount fixture
10 RESET button (reset all settings)
12 Battery compartment
14 RAIN ALERT button (set and enable pre-
cipitation alert)
15
14
13
