Viper AS1050R Use And Maintenance

Use and maintenance
Operating guidelines AS1050R
Disconnect battery charger
and store the cable.
Install the squeegee and fix it
by using the two knobs.
To install the brush/pad holder, pull up the metal handle and slide
in the brush/pad holder until it stops against the pins in the proper
position and release the handle. Put back the side skirt
Click One Touch button to
activate all functions
October 2020
Fill the solution tank with
fresh water and add low foam
detergent according to needs.
The water temperature must
not exceed 40 °C.
Adjust squeegee angle and
blade pressure for optimal
water pick-up by turning
the adjustment knob on
the support.
Adjust the maximum
speed with the speed
adjustment dial.
Solution level indicator is on the side of the tank showing current
level. If the solution tank is empty or recovery tank full, an indicator
on the display will show up with sound warning.
Loosen the two knobs to
remove the side skirt.
Turn the main key to on and press the click on button to install the brush
automatically. Deck will lower and brushes turn slowly to attach.
Use buttons to change
cleaning settings from the
dashboard
During the cleaning job it's
possible to adjust the solution
flow, the brush pressure,
activiting Eco Mode or Silent
Mode from the dashboard.
