cmotion cvolutionLCS User Manual page 109

Menu
Red
MOTOR M1 – M8, cforcexxx
Note: motors that are not
connected cannot be config-
ured.
3D MODE
TORQUE M1 – M8, cforcexxx
Note: motors that are not
connected cannot be config-
ured.
RAMP M1 – M8, cforcexxx
Note: motors that are not
connected cannot be config-
ured.
DIRECTION M1 – M8, cforcexxx
Note: motors that are not
connected cannot be config-
ured.
SYNC FOCUS, IRIS, ZOOM Scales,
CLEAR ALL
All content © 2017, cmotion GmbH. All specifications subject to change without notice. http://www.cmotion.eu
Menu Entry
REC, RET, UB 1, UB 2, UB 3, MARK, QSYN, RECM,
LASER, OFF
REC starts/stops the camera.
RET Trigger Return function when using an ARRI Alexa
camera and a RVI cable.
UB 1, UB 2, UB 3, triggers a camera function assigned
to a user button 1-3 on ARRI Alexa, Amira, Alexa Mini
and RED Weapon, Helium, Scarlett (in order to assign
user buttons on the camera, please refer to the corre-
sponding camera manual).
MARK is used for focus marks when used with cdis-
play and for auto focus with a cfinder.
QSYN is used for quick sync. Please refer to to section
6.1.3 on page 83 for details.
RECM is used for meta data recording (camin 8M-TC
only). Please refer to section 7 on page 93.
LASER activates the laser pointer of cfinder III as long
as the button is being pressed. (WARNING: Do not
point at eyes while the laser pointer is activated!)
OFF disables the button.
Focus, Iris, Zoom, Conv, Interaxial, Mirror, Tilt, Rotation
Select motor function. Default is dependent on camin
version. Each motor can be set to any function.
These functions are used with Screen Plane and other
3D rigs. Please refer to section 6 on page 84 for
more information.
min, weak, strong, max
Select motor torque for each motor. Please note that
using high motor torque on lenses with low drag can
result in motor jitter.
min, short, long, max
Select motor ramp for each motor. Use short ramps for
fast acceleration (e.g. on lenses) and long ramps for
smooth acceleration (e.g. on 3D rigs)
left, right
Sets the motor direction for each motor. This setting is
independent from the knob or slider direction, allowing
to move motors in opposite direction while using knob
or slider (for example on 3D rigs).
This setting allows to save up to 32 sync points to
match lenses for 3D/Panoramic operation. Refer to
section 6.1 on page 84 for more information.
Options
