6.7. Troubleshooting

If you experience an difficulties, please follow these step:
■AutoConv: If you can set the screen plane, but the angle does not change
accordingly, make sure you have properly set the zero point.
■Interaxial/Convergence: If the display shows an inverted value, try changing the
Motor Direction for that axis.
If the problem persists, reset you system to Factory Preset and re-setup as per instructions. To
reset the system:
■Enter the MAIN MENU, scroll to "MAIN".
■Enter and select "Factory Settings". Press "select" and confirm by pressing
"select" again
■Contact cmotion if any of these instructions fail to solve your problem. Have
your system components' serial numbers and software versions at hand when
contacting us.

6.8. Screen Plane

The cvolution lens control system is also capable of controlling Screen Plane, P+S technik and
other custom 3D rigs with the cdisplay II and the cscreenplane software.
Please refer to the Screen Plane User Guide for documentation on Screen Plane 3D functions.
