NuTone 883001 Specification Sheet

MODEL 88000
CONVERTIBLE
MICROTEK
RANGE HOOD
A top-of-the-line hood with a multi-layer duct-
free filter system unequalled in the industry.
FEATURES
•
Infinite speed slide control with solid state blower
memory
•
Two-position light switch for "bright" or "night-light"
illumination
•
Bright polymeric light lens (accepts 2 - 75W bulbs)
•
High efficiency dual centrifugal blower with resilient
anti-vibration motor mounts
•
Broan Heat Sentry TM - automatically turns blower to high
speed when excess cooking heat is detected
•
Two washable aluminum filters
•
®
Twin Microtek System IV filters for optimum capture
of cooking contaminants in the duct-free mode
(purchase separately)
•
Mitered sides and hemmed bottom for safety and good
looks
•
Contemporary styling in White, Almond, Black, White-
on-White, Stainless Steel and Biscuit
•
Available in 30", 36" and 42" widths
•
Special Order Sizes - 33" and 39" (White, Almond and
Stainless Steel and Biscuit only)
•
Special Order Size - 48" (All colors)
SPECIFICATIONS
SONES
VOLTS AMPS RPM VER. HOR. VER. HOR.
120 4.5 1550 5.5 6.0
HVI certified ratings comply with testing procedures prescribed
by the Home Ventilating Institute. Ratings are at 0.1 in. static
pressure. Sones are a measure of loudness and are measured
in HVI's semi-reverberant sound test room.
*RHP INDEX (Range Hood Performance) is a scientific measure
of the effectiveness of a range hood in removing grease, smoke,
dirt and other solid pollutants from the air. The RHP Index
compares the performance of each hood to others.
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
REFERENCE QTY.
®
SYSTEM IV
CFM
DUCTFREE
RHPINDEX* DUCT
360 350 59.09 3-1/4" x 10"
REMARKS
SPECIFICATION SHEET
TYPICAL SPECIFICATION
Range hood shall be Broan Model 88000.
Unit shall be convertible between ducted (using washable
aluminum filters) and duct-free (using Microtek
filters).
Unit shall have a permanently lubricated, dual centrifugal
blower, resiliently mounted and controlled with an infinite
speed, solid state control. RPM not to exceed 1550. Hood
shall have a separate, two-position light switch.
Sides shall be mitered and bottom hemmed - with no
sharp edges.
Air delivery shall be no less than 360 CFM and sound
levels no greater than 5.5 Sones (vertical discharge), 350
CFM and 6.0 Sones (horizontal discharge). All air and
sound ratings shall be certified by HVI.
Unit shall be U.L. listed.
Project
Location
Architect
Engineer
Contractor
Submitted by
® System IV
Date
10H 99041061K
