NuTone 433011 Specification Sheet

43000 SERIES
RANGE HOOD
Choose this 4-way convertible hood for round and
rectangular ducted, as well as non-ducted
configurations.
FEATURES
• 4-way convertible - can be ducted using 7" round or 3¼" x
10" steel ductwork or installed non-ducted
• Includes 3¼" x 10" damper (7" round – purchase Model
BP87 damper)
• Includes washable aluminum filter with light lens (non-
ducted filter purchased separately)
• Powerful, yet quiet motor and blade combination delivers
200 cfm
• Two-speed rocker switch controls fan
• 75 Watt maximum incandescent light controlled by single
rocker switch
• Finished with durable, environmentally friendly, advanced
technology powder coating
• All edges hemmed for safety and strength
• Available in 30" and 36" widths in White-on-White, Almond-
on-Almond, Biscuit-on-Biscuit, and Stainless Steel finishes
SPECIFICATIONS
VOLTS HZ. AMPS
115 60 1.8
115 60 1.8
115 60 1.8
HVI-2100 CERTIFIED RATINGS comply with new
testing technologies and procedures prescribed by
the Home Ventilating Institute, for off-the-shelf
products, as they are available to consumers. Product
performance is rated at 0.1 in. static pressure, based
on tests conducted in AMCA's state-of-the-art test
laboratory. Sones are a measure of humanly-
perceived loudness, based on laboratory
measurements.
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
REFERENCE QTY.
CFM SONES DUCT
160 7.0 3¼" x 10" (H)
190 7.0 3¼" x 10" (V)
220 8.0 7" Round (V)
REMARKS
SPECIFICATION SHEET
TYPICAL SPECIFICATION
The range hood shall be a Broan 43000 Series.
Hood to be 30" (36") in width and finished with White
(Almond) (Biscuit) powder-coat or constructed of stainless
steel. All exposed edges to be hemmed.
Range hood will be convertible between 7" round, 3¼" x 10"
rectangular (vertical or horizontal), and non-ducted dis-
charges. A 3¼" x 10" damper to be included.
Hood shall have a washable aluminum filter and covered
light. Incandescent light bulb to be 75 watts maximum.
Range hood to be controlled with two-speed rocker switch for
fan and single rocker switch for light.
Air delivery shall be no less than 160 CFM and sound levels
no greater than 7.0 Sones (3¼" x 10" horizontal discharge),
190 CFM at 7.0 Sones (3¼" x 10" vertical discharge), or 220
CFM at 8.0 Sones (7" round discharge). All air and sound
ratings shall be certified by HVI.
Range hood shall be U.L. listed.
Project
Location
Architect
Engineer
Contractor
Submitted by
10E
Date
99042442C
